Streaming Geopoint data from Kafka to Elasticsearch

Streaming data from Kafka to Elasticsearch is easy with Kafka Connect - you can see how in this tutorial and video.

One of the things that sometimes causes issues though is how to get location data correctly indexed into Elasticsearch as geo_point fields to enable all that lovely location analysis. Unlike data types like dates and numerics, Elasticsearch’s Dynamic Field Mapping won’t automagically pick up geo_point data, and so you have to do two things:

Declare the index mapping in full, or use a dynamic template to tell Elasticsearch to create new fields as a geo_point if they match the given pattern
Make sure that your geo_point source data is in the structure that Elasticsearch requires, covered in full here but basically:
- object/struct
  "location": { "lat": 41.12, "lon": -71.34 }
  the field names are case sensitive
- string
  "location": "41.12,-71.34"
- array
  "location": [ -71.34, 41.12 ]
- plus geohash and WKT POINT.

How? 🔗

To get the data into the necessary format you can use ksqlDB to wrangle it, which is what I show below.

You could also use Kafka Connect’s Single Message Transform feature but no existing transformation exists that I’m aware of that does the necessary - drop me a line if you write one!

Example 🔗

Here’s a worked example showing how to do this. It assumes that you’ve got a source topic with latitude and longitude, in this case it’s already as a struct but with the incorrect capitalisation ("Location": { "Lat": 43.7575119, "Lon": 11.2921363 }).

Populate source topic with the sample data:

kafkacat -b localhost:9092 -P -t input_topic <<EOF
{ "ID": "7d6203f4-3ae7-4daa-af03-71f98d619f7e", "Timestamp": "2020-11-02T12:05:57.87639003Z", "Type": "CREATION", "PlaceType": "home", "Location": { "Lat": 43.7575119, "Lon": 11.2921363 }, "Created": "2020-11-02T12:05:57.876390266Z", "LastUpdated": "2020-11-02T12:05:57.876390398Z" }
EOF

Taking a source topic of source, declare the ksqlDB STREAM object (which is basically Kafka topic with a schema overlaid):

CREATE STREAM SOURCE_STREAM (ID VARCHAR,
                            Timestamp VARCHAR,
                            Type VARCHAR,
                            PlaceType VARCHAR,
                            Location STRUCT<Lat DOUBLE, Lon DOUBLE>,
                            Created VARCHAR,
                            LastUpdated VARCHAR)
        WITH (KAFKA_TOPIC='input_topic',
            VALUE_FORMAT='JSON');

Confirm that the stream’s schema is valid by selecting fields from the first message:

ksql> SET 'auto.offset.reset' = 'earliest';
>
Successfully changed local property 'auto.offset.reset' to 'earliest'. Use the UNSET command to revert your change.

ksql> SELECT ID, PLACETYPE, LOCATION->LAT, LOCATION->LON FROM SOURCE_STREAM EMIT CHANGES LIMIT 1;
+---------------------------------------+----------+-----------+-----------+
|ID                                     |PLACETYPE |LAT        |LON        |
+---------------------------------------+----------+-----------+-----------+
|7d6203f4-3ae7-4daa-af03-71f98d619f7e   |home      |43.7575119 |11.2921363 |
Limit Reached
Query terminated

Create a target stream, mapping the lat/lon fields to lower-case names. Here I’m also showing the alternative approach of concatenating them, which Elasticsearch will also accept:

CREATE STREAM TARGET_STREAM WITH (KAFKA_TOPIC='target_topic') AS
    SELECT *,
        STRUCT("lat" := LOCATION->LAT, "lon":= LOCATION->LON) AS "location_example_01",
        CAST(LOCATION->LAT AS VARCHAR)  + ',' + CAST(LOCATION->LON AS VARCHAR) AS "location_example_02"
    FROM SOURCE_STREAM;

Create an index template for Elasticsearch if the index does not already have the geo_point mapping declared. Here it’ll match any index created that begins with target

curl --silent --show-error -XPUT -H 'Content-Type: application/json' \
    http://localhost:9200/_index_template/rmoff_template01/ \
    -d'{
        "index_patterns": [ "target*" ],
        "template": {
            "mappings": {
                "properties": {
                    "location_example_01": {
                        "type": "geo_point"
                    },
                    "location_example_02": {
                        "type": "geo_point"
                    }
                }
            }
        } }'

Stream the data from Kafka to Elasticsearch using Kafka Connect. You can do configure this using the native Kafka Connect REST API, or do it directly from ksqlDB itself:

CREATE SINK CONNECTOR SINK_ELASTIC_01 WITH (
'connector.class'                     = 'io.confluent.connect.elasticsearch.ElasticsearchSinkConnector',
'topics'                              = 'target_topic',
'key.converter'                       = 'org.apache.kafka.connect.storage.StringConverter',
'value.converter'                     = 'org.apache.kafka.connect.json.JsonConverter',
'value.converter.schemas.enable'      = 'false',
'connection.url'                      = 'http://elasticsearch:9200',
'type.name'                           = '_doc',
'key.ignore'                          = 'true',
'schema.ignore'                       = 'true');

Inspect the mappings in the new Elasticsearch index

curl -XGET --silent --show-error http://localhost:9200"/target_topic/_mappings"  | jq '.'
{
"target_topic": {
    "mappings": {
    "properties": {
        "CREATED": {
        "type": "date"
        },
        "ID": {
        "type": "text",
        "fields": {
            "keyword": {
            "type": "keyword",
            "ignore_above": 256
            }
        }
        },
        "LASTUPDATED": {
        "type": "date"
        },
        "LOCATION": {
        "properties": {
            "LAT": {
            "type": "float"
            },
            "LON": {
            "type": "float"
            }
        }
        },
        "PLACETYPE": {
        "type": "text",
        "fields": {
            "keyword": {
            "type": "keyword",
            "ignore_above": 256
            }
        }
        },
        "TIMESTAMP": {
        "type": "date"
        },
        "TYPE": {
        "type": "text",
        "fields": {
            "keyword": {
            "type": "keyword",
            "ignore_above": 256
            }
        }
        },
        "location_example_01": {
        "type": "geo_point"
        },
        "location_example_02": {
        "type": "geo_point"
        }
    }
    }
}
}

View the data:

Learn more about streaming data from Kafka into Elasticsearch 🔗

Try out the tutorial for yourself!
