With my foray into the current world of data engineering I wanted to get my hands dirty with some of the tools and technologies I’d been reading about. The vehicle for this was trying to understand more about LakeFS, but along the way dabbling with PySpark and S3 (MinIO) too.

I’d forgotten how amazingly useful notebooks are. It’s six years since I wrote about them last (and the last time I tried my hand at PySpark). This blog is basically the notebook, with some more annotations.

If you want to run it yourself you can download the notebook and run it on the Everything Bagel Docker Compose environment from LakeFS.

tl;dr đŸ”—

With LakeFS you can branch and merge your data just as you would with your code. You can work on a copy of your main dataset to test new code without worrying about overwriting it. You can test destructive changes without committing them until you’re sure they work.

See more thoughts on it here.

Overview đŸ”—

I wanted to understand and see for myself how LakeFS brings the concept of git to data, and what it looks like in practice.

I start off with a main branch and write some data to it (as a Parquet file).

From there I create two branches, in which I

Along the way I compare how LakeFS reports the files (acting as a S3 proxy), and what’s happening in the actual S3 storage underneath. The latter’s interesting because LakeFS does “copy on write”, whereby data’s not duplicated until it needs to be written (i.e. when, and only when, it changes). This CoW approach is great for storage efficiency, and a solid reason why you’d be looking at something like LakeFS instead of simply actually duplicating data on S3 when you want to test something.

Set up connections đŸ”—

S3 đŸ”—

Connection is configured here

import boto3

s3 = boto3.resource('s3',
                  endpoint_url='http://minio:9000/',
                  aws_access_key_id='minioadmin',
                  aws_secret_access_key='minioadmin')

LakeFS đŸ”—

import lakefs_client
from lakefs_client import models
from lakefs_client.client import LakeFSClient
from lakefs_client.api import branches_api
from lakefs_client.api import commits_api

# lakeFS credentials and endpoint
configuration = lakefs_client.Configuration()
configuration.username = 'AKIAIOSFODNN7EXAMPLE'
configuration.password = 'wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY'
configuration.host = 'http://lakefs:8000'

client = LakeFSClient(configuration)
api_client = lakefs_client.ApiClient(configuration)

Spark đŸ”—

from pyspark.context import SparkContext
from pyspark import SparkFiles
from pyspark.sql.session import SparkSession
sc = SparkContext('local')
spark = SparkSession(sc)

List the current branches in the repository đŸ”—

https://pydocs.lakefs.io/docs/BranchesApi.html#list_branches

repo='example'

for b in client.branches.list_branches(repo).results:
    display(b.id)

'main'

Load and write some data to the main branch đŸ”—

To start with we take a random parquet data file that I found on github, load it, and write it to S3 on the main branch of the repository.

url='https://github.com/Teradata/kylo/blob/master/samples/sample-data/parquet/userdata1.parquet?raw=true'
sc.addFile(url)
df = spark.read.parquet("file://" + SparkFiles.get("userdata1.parquet"))

Inspect the data:

display(df.count())

1000

What does the data look like?

df.show(n=1,vertical=True)

-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 email             | [email protected]
 gender            | Female
 ip_address        | 1.197.201.2
 cc                | 6759521864920116
 country           | Indonesia
 birthdate         | 3/8/1971
 salary            | 49756.53
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

Write data to S3 đŸ”—

branch='main'

df.write.mode('overwrite').parquet('s3a://'+repo+'/'+branch+'/demo/users')

Exploring LakeFS đŸ”—

Let’s see how LakeFS handles and see the file that we’ve just written, and then how to commit it to the branch.

The data as seen from LakeFS đŸ”—

https://pydocs.lakefs.io/docs/ObjectsApi.html#list_objects

Note the physical_address and its match in the S3 output in the next step

client.objects.list_objects(repo,branch).results

[{'checksum': 'd41d8cd98f00b204e9800998ecf8427e',
  'content_type': 'application/octet-stream',
  'mtime': 1663316305,
  'path': 'demo/users/_SUCCESS',
  'path_type': 'object',
  'physical_address': 's3://example/5e91c0a09d3a4415abd33bc460662e18',
  'size_bytes': 0},
 {'checksum': 'addfab49d691a5d4a18ae0b127a792a0',
  'content_type': 'application/octet-stream',
  'mtime': 1663316304,
  'path': 'demo/users/part-00000-142e4126-aaec-477c-bbcf-c1dd68011369-c000.snappy.parquet',
  'path_type': 'object',
  'physical_address': 's3://example/2895bba44b5b4f5199bf58d80144a9de',
  'size_bytes': 78869}]

The data as seen from S3 đŸ”—

for o in s3.Bucket(repo).objects.all():
    print(o.last_modified, o.key, o.size)

2022-09-16 08:18:24.769000+00:00 1984e4e69777452fb03800bd4c6b1b05 0
2022-09-16 08:18:23.607000+00:00 2895bba44b5b4f5199bf58d80144a9de 78869
2022-09-16 08:18:22.900000+00:00 49ad588d52b942c9b682f271f228cb9c 0
2022-09-16 08:18:25.034000+00:00 5e91c0a09d3a4415abd33bc460662e18 0
2022-09-16 08:18:24.277000+00:00 c4cae27b7c0a46beb14f79347d77c29d 0
2022-09-16 08:17:18.615000+00:00 dummy 70

List diff of branch in LakeFS (this is kinda like a git status) đŸ”—

https://pydocs.lakefs.io/docs/BranchesApi.html#diff_branch

Note that the files show 'type': 'added'

api_instance = branches_api.BranchesApi(api_client)

api_response = api_instance.diff_branch(repo, branch)
if api_response.pagination.results==0:
    display("Nothing to commit")
else:
    for r in api_response.results:
        display(r)

{'path': 'demo/users/_SUCCESS',
 'path_type': 'object',
 'size_bytes': 78869,
 'type': 'added'}



{'path': 'demo/users/part-00000-142e4126-aaec-477c-bbcf-c1dd68011369-c000.snappy.parquet',
 'path_type': 'object',
 'size_bytes': 78869,
 'type': 'added'}

Commit the new file in main đŸ”—

https://pydocs.lakefs.io/docs/CommitsApi.html#commit

from lakefs_client.api import commits_api
from lakefs_client.model.commit import Commit
from lakefs_client.model.commit_creation import CommitCreation

api_instance = commits_api.CommitsApi(api_client)
commit_creation = CommitCreation(
    message="Everything Bagel - commit users data (original)",
    metadata={
        "foo": "bar",
    }
)

api_instance.commit(repo, branch, commit_creation)

{'committer': 'docker',
 'creation_date': 1663316414,
 'id': 'de2ae0f24961f65bf7b525d983b3dbc869ce49a0dea43529920743154ce0ddd0',
 'message': 'Everything Bagel - commit users data (original)',
 'meta_range_id': '',
 'metadata': {'foo': 'bar'},
 'parents': ['a3bfc3317b697cb671665ea44b05b4009a06404c95c56a705fe638a824f1c04e']}

List branch status again - nothing returned means that there is nothing uncommitted đŸ”—

api_instance = branches_api.BranchesApi(api_client)

api_response = api_instance.diff_branch(repo, branch)
if api_response.pagination.results==0:
    display("Nothing to commit")
else:
    for r in api_response.results:
        display(r)

'Nothing to commit'

Similar to a git status showing Your branch is up to date with 'main' / nothing to commit, working tree clean

Branching to test new code đŸ”—

Now that we’ve got our main branch set up, let’s explore what we can do with. Imagine we have a couple of things that we’re working on and want to try out without touching the main dataset (at least until we know that they work).

First we’ll test adding new data, and create a branch on which to try it.

https://pydocs.lakefs.io/docs/BranchesApi.html#create_branch

Note that at this point there’s no additional object created on the object store

branch='add_more_user_data'

from lakefs_client.model.branch_creation import BranchCreation

api_instance = branches_api.BranchesApi(api_client)
branch_creation = BranchCreation(
    name=branch,
    source="main",
)

api_response = api_instance.create_branch(repo, branch_creation)
display(api_response)

'de2ae0f24961f65bf7b525d983b3dbc869ce49a0dea43529920743154ce0ddd0'

List the current branches in the example repository đŸ”—

https://pydocs.lakefs.io/docs/BranchesApi.html#list_branches

for b in client.branches.list_branches(repo).results:
    display(b.id)

'add_more_user_data'
'main'

Read the existing data đŸ”—

Note that we’re reading from the new branch, and see the data that was committed to main.

xform_df = spark.read.parquet('s3a://'+repo+'/'+branch+'/demo/users')

How many rows of data?

display(xform_df.count())

1000

What does the data look like?

xform_df.show(n=1,vertical=True)

-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 email             | [email protected]
 gender            | Female
 ip_address        | 1.197.201.2
 cc                | 6759521864920116
 country           | Indonesia
 birthdate         | 3/8/1971
 salary            | 49756.53
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

Add some new data đŸ”—

We’ll download another file from the same source as originally. It’s userdata2 this time, instead of the userdata1 used above.

url='https://github.com/Teradata/kylo/blob/master/samples/sample-data/parquet/userdata2.parquet?raw=true'
sc.addFile(url)
df = spark.read.parquet("file://" + SparkFiles.get("userdata2.parquet"))

Look at the new data:

df.show(n=1,vertical=True)

-RECORD 0---------------------------------
 registration_dttm | 2016-02-03 13:36:39
 id                | 1
 first_name        | Donald
 last_name         | Lewis
 email             | dlewis0@clickbank...
 gender            | Male
 ip_address        | 102.22.124.20
 cc                |
 country           | Indonesia
 birthdate         | 7/9/1972
 salary            | 140249.37
 title             | Senior Financial ...
 comments          |
only showing top 1 row

Write the data (to the branch) and commit it đŸ”—

df.write.mode('append').parquet('s3a://'+repo+'/'+branch+'/demo/users')

LakeFS sees that there is an uncommited change

api_instance = branches_api.BranchesApi(api_client)

api_response = api_instance.diff_branch(repo, branch)
if api_response.pagination.results==0:
    display("Nothing to commit")
else:
    for r in api_response.results:
        display(r)

{'path': 'demo/users/part-00000-b90910aa-58a0-42af-84ec-8ec557c56850-c000.snappy.parquet',
 'path_type': 'object',
 'size_bytes': 78729,
 'type': 'added'}

Commit it

from lakefs_client.api import commits_api
from lakefs_client.model.commit import Commit
from lakefs_client.model.commit_creation import CommitCreation

api_instance = commits_api.CommitsApi(api_client)
commit_creation = CommitCreation(
    message="Everything Bagel - add more user data",
    metadata={
        "foo": "bar",
    }
)

api_instance.commit(repo, branch, commit_creation)

{'committer': 'docker',
 'creation_date': 1663316722,
 'id': '9d7f809d1733ee0f48d89fd6d5d1d915aaf79200e10f26e997db1437b3414794',
 'message': 'Everything Bagel - add more user data',
 'meta_range_id': '',
 'metadata': {'foo': 'bar'},
 'parents': ['de2ae0f24961f65bf7b525d983b3dbc869ce49a0dea43529920743154ce0ddd0']}

Status check: how’s the data look from each branch? đŸ”—

Let’s re-read the main and add_more_user_data branches and count the rows in each

Original branch (main):

add_more_user_data = spark.read.parquet('s3a://'+repo+'/main/demo/users')
display(add_more_user_data.count())

1000

New branch (add_more_user_data):

add_more_user_data = spark.read.parquet('s3a://'+repo+'/add_more_user_data/demo/users')
display(add_more_user_data.count())

2000

Look at the view in LakeFS đŸ”—

main đŸ”—

client.objects.list_objects(repo,'main').results

[{'checksum': 'd41d8cd98f00b204e9800998ecf8427e',
  'content_type': 'application/octet-stream',
  'mtime': 1663316305,
  'path': 'demo/users/_SUCCESS',
  'path_type': 'object',
  'physical_address': 's3://example/5e91c0a09d3a4415abd33bc460662e18',
  'size_bytes': 0},
 {'checksum': 'addfab49d691a5d4a18ae0b127a792a0',
  'content_type': 'application/octet-stream',
  'mtime': 1663316304,
  'path': 'demo/users/part-00000-142e4126-aaec-477c-bbcf-c1dd68011369-c000.snappy.parquet',
  'path_type': 'object',
  'physical_address': 's3://example/2895bba44b5b4f5199bf58d80144a9de',
  'size_bytes': 78869}]

add_more_user_data đŸ”—

client.objects.list_objects(repo,'add_more_user_data').results

[{'checksum': 'd41d8cd98f00b204e9800998ecf8427e',
  'content_type': 'application/octet-stream',
  'mtime': 1663316556,
  'path': 'demo/users/_SUCCESS',
  'path_type': 'object',
  'physical_address': 's3://example/8acafaeee021459ba6cc29cfb35bb06b',
  'size_bytes': 0},
 {'checksum': 'addfab49d691a5d4a18ae0b127a792a0',
  'content_type': 'application/octet-stream',
  'mtime': 1663316304,
  'path': 'demo/users/part-00000-142e4126-aaec-477c-bbcf-c1dd68011369-c000.snappy.parquet',
  'path_type': 'object',
  'physical_address': 's3://example/2895bba44b5b4f5199bf58d80144a9de',
  'size_bytes': 78869},
 {'checksum': '90bee97b5d4bf0675f2684664e5993dc',
  'content_type': 'application/octet-stream',
  'mtime': 1663316555,
  'path': 'demo/users/part-00000-b90910aa-58a0-42af-84ec-8ec557c56850-c000.snappy.parquet',
  'path_type': 'object',
  'physical_address': 's3://example/ece3333dd6bd4d6d9ffab3d53fd4e6b2',
  'size_bytes': 78729}]

The data as seen from S3 đŸ”—

Note that there are just two 78k files; there is no duplication of data shared by branches.

for o in s3.Bucket(repo).objects.all():
    print(o.last_modified, o.key, o.size)

2022-09-16 08:18:24.769000+00:00 1984e4e69777452fb03800bd4c6b1b05 0
2022-09-16 08:18:23.607000+00:00 2895bba44b5b4f5199bf58d80144a9de 78869
2022-09-16 08:22:35.628000+00:00 31d780e5af4140e895a7c3779fac985d 0
2022-09-16 08:22:36.105000+00:00 3aec1fd8560f43aaa8667d0b2d3a70be 0
2022-09-16 08:18:22.900000+00:00 49ad588d52b942c9b682f271f228cb9c 0
2022-09-16 08:18:25.034000+00:00 5e91c0a09d3a4415abd33bc460662e18 0
2022-09-16 08:22:36.360000+00:00 8acafaeee021459ba6cc29cfb35bb06b 0
2022-09-16 08:25:22.454000+00:00 _lakefs/1ddeab3bef4929b69d52e44b94048f47fe17269821ccdf3ba6701c43d691fb34 1239
2022-09-16 08:20:14.890000+00:00 _lakefs/6f2ea862d75cb1a2cdb4a3a76969c2bb134c51538c74c0d144b781ed12165b83 1390
2022-09-16 08:20:14.903000+00:00 _lakefs/ae52ce4551b3d0fd1eb49a8568f4a65db007f222953dd2770d55e0f13c4aaeb9 1239
2022-09-16 08:25:22.447000+00:00 _lakefs/dedf8f514dcf0bb4184e9ebd55ceddcfafc9fb9fd02888566a0ad2052cfb7c12 1609
2022-09-16 08:22:34.689000+00:00 b3cf0d04badd411da874a6448eead32f 0
2022-09-16 08:18:24.277000+00:00 c4cae27b7c0a46beb14f79347d77c29d 0
2022-09-16 08:17:18.615000+00:00 dummy 70
2022-09-16 08:22:35.017000+00:00 ece3333dd6bd4d6d9ffab3d53fd4e6b2 78729

Creating another new branch đŸ”—

We’ve not merged the new user data back into main yet, but in parallel we decide we want to test removing personally identifiable information (PII) from the data that we do have already. We can create another branch to do this.

branch='remove_pii'

from lakefs_client.model.branch_creation import BranchCreation

api_instance = branches_api.BranchesApi(api_client)
branch_creation = BranchCreation(
    name=branch,
    source="main",
)

api_response = api_instance.create_branch(repo, branch_creation)
display(api_response)

'de2ae0f24961f65bf7b525d983b3dbc869ce49a0dea43529920743154ce0ddd0'

First off we’ll confirm that the data in this new branch matches what’s in main (a row count alone will suffice for a quick check):

xform_df = spark.read.parquet('s3a://'+repo+'/'+branch+'/demo/users')

display(xform_df.count())

1000

Note that this shows 1000 per main, and not 2000 per the add_more_user_data branch above since this has not been merged to main

Transform the data đŸ”—

Now we’ll use .drop() to remove sensitive fields from the data.

df2=xform_df.drop('ip_address','birthdate','salary','email').cache()
df2.show(n=1,vertical=True)

-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 gender            | Female
 cc                | 6759521864920116
 country           | Indonesia
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

Write data back to the branch đŸ”—

df2.write.mode('overwrite').parquet('s3a://'+repo+'/'+branch+'/demo/users')

Commit changes đŸ”—

api_instance = commits_api.CommitsApi(api_client)
commit_creation = CommitCreation(
    message="Remove PII",
)

api_instance.commit(repo, branch, commit_creation)

{'committer': 'docker',
 'creation_date': 1663322293,
 'id': '12718ce62f97df78beb1d49dcd4c5528a1977d2af1b220f22012f8305e72f768',
 'message': 'Remove PII',
 'meta_range_id': '',
 'metadata': {},
 'parents': ['de2ae0f24961f65bf7b525d983b3dbc869ce49a0dea43529920743154ce0ddd0']}

ℹī¸ Reading and writing the same data back đŸ”—

If you try to read and then write the data from the same place you’ll get an error like this:

Caused by: java.io.FileNotFoundException:
No such file or directory: s3a://example/remove_pii/demo/users/part-00000-7a0bbe79-a3e2-4355-984e-bd8b950a4e0c-c000.snappy.parquet

One solution is to use .cache(). Alternatively (and probably better, is to read the data from a different path - the reference point from which the branch was created)

Thanks to Barak Amar on the LakeFS Slack for helping me with this.

Re-read all branches and inspect data for isolation đŸ”—

Here’s the original branch (main), with 1k records and full set of fields:

main = spark.read.parquet('s3a://'+repo+'/main/demo/users')
display(main.count())
main.show(n=1,vertical=True)

1000


-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 email             | [email protected]
 gender            | Female
 ip_address        | 1.197.201.2
 cc                | 6759521864920116
 country           | Indonesia
 birthdate         | 3/8/1971
 salary            | 49756.53
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

The branch to which we added more data still has that data (as we’d expect; we’ve not touched it):

add_more_user_data = spark.read.parquet('s3a://'+repo+'/add_more_user_data/demo/users')
display(add_more_user_data.count())
add_more_user_data.show(n=1,vertical=True)

2000


-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 email             | [email protected]
 gender            | Female
 ip_address        | 1.197.201.2
 cc                | 6759521864920116
 country           | Indonesia
 birthdate         | 3/8/1971
 salary            | 49756.53
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

And our new branch for removing PII is showing the correct data too: (remove_pii):

remove_pii = spark.read.parquet('s3a://'+repo+'/remove_pii/demo/users')
display(remove_pii.count())
remove_pii.show(n=1,vertical=True)

1000


-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 gender            | Female
 cc                | 6759521864920116
 country           | Indonesia
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

Merge remove_pii into main đŸ”—

Since we’re happy with the data transform work, we’ll merge the result into main.

client.refs.merge_into_branch(repository=repo, source_ref='remove_pii', destination_branch='main')

{'reference': 'bb4564d3811586db5db202e8553fa5bfc4c5a235c4d8b8ec22ab62f7ab43b34c',
 'summary': {'added': 0, 'changed': 0, 'conflict': 0, 'removed': 0}}

Now if we read the data from the original branch (main), we can see that it’s what we merged in, as expected:

main = spark.read.parquet('s3a://'+repo+'/main/demo/users')
display(main.count())
main.show(n=1,vertical=True)

1000


-RECORD 0--------------------------------
 registration_dttm | 2016-02-03 07:55:29
 id                | 1
 first_name        | Amanda
 last_name         | Jordan
 gender            | Female
 cc                | 6759521864920116
 country           | Indonesia
 title             | Internal Auditor
 comments          | 1E+02
only showing top 1 row

Data Engineering in 2022 đŸ”—
