I started my dbt journey by poking and pulling at the pre-built jaffle_shop demo running with DuckDB as its data store. Now I want to see if I can put it to use myself to wrangle the session feedback data that came in from Current 2022. Iβve analysed this already, but it struck me that a particular part of it would benefit from some tidying up - and be a good excuse to see what itβs like using dbt to do so.
Set up π
Iβm going to use DuckDB as my datastore because itβs local and all I need at this point. Because of that, Iβll crib salient sections from the jaffle_shop_duckdb demo, as well as make use of the dbt getting started docs.
# Create a project folder
mkdir current-dbt
# Copy the requirements from jaffle_shop_duckdb
cp ../jaffle_shop_duckdb/requirements.txt .
# Download deps and init the environment
python3 -m venv venv
source venv/bin/activate
python3 -m pip install --upgrade pip
python3 -m pip install -r requirements.txt
source venv/bin/activate
Create a β¨sparkly new dbt projectβ¨ with dbt init
:
$ dbt init
16:40:45 Running with dbt=1.1.1
16:40:45 Creating dbt configuration folder at /Users/rmoff/.dbt
Enter a name for your project (letters, digits, underscore): current_dbt
Which database would you like to use?
[1] postgres
[2] duckdb
(Don't see the one you want? https://docs.getdbt.com/docs/available-adapters)
Enter a number: 2
16:41:03 No sample profile found for duckdb.
16:41:03
Your new dbt project "current_dbt" was created!
For more information on how to configure the profiles.yml file,
please consult the dbt documentation here:
https://docs.getdbt.com/docs/configure-your-profile
One more thing:
Need help? Don't hesitate to reach out to us via GitHub issues or on Slack:
https://community.getdbt.com/
Happy modeling!
From this I get a dbt project structure on disk:
$ ls -lR current_dbt
total 16
-rw-r--r-- 1 rmoff staff 571 20 Oct 17:29 README.md
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 analyses
-rw-r--r-- 1 rmoff staff 1337 20 Oct 17:40 dbt_project.yml
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 macros
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 models
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 seeds
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 snapshots
drwxr-xr-x 3 rmoff staff 96 20 Oct 17:31 tests
current_dbt/analyses:
total 0
current_dbt/macros:
total 0
current_dbt/models:
total 0
drwxr-xr-x 5 rmoff staff 160 20 Oct 17:31 example
current_dbt/models/example:
total 24
-rw-r--r-- 1 rmoff staff 475 20 Oct 17:29 my_first_dbt_model.sql
-rw-r--r-- 1 rmoff staff 115 20 Oct 17:29 my_second_dbt_model.sql
-rw-r--r-- 1 rmoff staff 437 20 Oct 17:29 schema.yml
current_dbt/seeds:
total 0
current_dbt/snapshots:
total 0
current_dbt/tests:
total 0
To this Iβm going to add the profiles.yml
from the jaffle_shop_duckdb demo and update it for my project.
current_dbt:
target: dev
outputs:
dev:
type: duckdb
path: 'current_dbt.duckdb'
threads: 1
So now my root dbt project folder looks like this:
-rw-r--r-- 1 rmoff staff 571B 20 Oct 17:29 README.md
drwxr-xr-x 3 rmoff staff 96B 20 Oct 17:31 analyses
-rw-r--r-- 1 rmoff staff 1.3K 20 Oct 17:40 dbt_project.yml
drwxr-xr-x 3 rmoff staff 96B 20 Oct 17:31 macros
drwxr-xr-x 3 rmoff staff 96B 20 Oct 17:31 models
-rw-r--r-- 1 rmoff staff 118B 21 Oct 09:50 profiles.yml
drwxr-xr-x 5 rmoff staff 160B 21 Oct 10:00 seeds
drwxr-xr-x 3 rmoff staff 96B 20 Oct 17:31 snapshots
drwxr-xr-x 3 rmoff staff 96B 20 Oct 17:31 tests
Source Data π
The source data is two files:
-
Session ratings - feedback left by attendees
-
Session scans - number of attendees per session by badge scan count
Both are CSV exports, which Iβve placed in the current_dbt/seeds
folder.
To start with Iβm simply going to see if I can use dbt seed
to load these into DuckDB.
$ dbt seed
09:03:19 Running with dbt=1.1.1
09:03:19 Partial parse save file not found. Starting full parse.
09:03:20 Found 2 models, 4 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
09:03:20
09:03:20 Concurrency: 1 threads (target='dev')
09:03:20
09:03:20 1 of 2 START seed file main.rating_detail ...................................... [RUN]
09:03:21 1 of 2 OK loaded seed file main.rating_detail .................................. [INSERT 2416 in 0.61s]
09:03:21 2 of 2 START seed file main.session_scans ...................................... [RUN]
09:03:21 2 of 2 OK loaded seed file main.session_scans .................................. [INSERT 163 in 0.10s]
09:03:21
09:03:21 Finished running 2 seeds in 0.86s.
09:03:21
09:03:21 Completed successfully
09:03:21
09:03:21 Done. PASS=2 WARN=0 ERROR=0 SKIP=0 TOTAL=2
Holy smokes! Thereβs now a DuckDB file created, and within it two tables holding data! And all I did was drop two CSV files into a folder and run dbt seed
.
$ ls -l *.duckdb
-rw-r--r-- 1 rmoff staff 2109440 21 Oct 10:03 current_dbt.duckdb
current_dbt.duckdb> \dt
+---------------+
| name |
+---------------+
| rating_detail |
| session_scans |
+---------------+
Time: 0.018s
current_dbt.duckdb> describe session_scans;
+-----+--------------------------------------------------------+---------+---------+------------+-------+
| cid | name | type | notnull | dflt_value | pk |
+-----+--------------------------------------------------------+---------+---------+------------+-------+
| 0 | Session Code | VARCHAR | False | <null> | False |
| 1 | Day | VARCHAR | False | <null> | False |
| 2 | Start | VARCHAR | False | <null> | False |
| 3 | End | VARCHAR | False | <null> | False |
| 4 | Speakers | VARCHAR | False | <null> | False |
| 5 | Name | VARCHAR | False | <null> | False |
| 6 | Scans | VARCHAR | False | <null> | False |
| 7 | Location | VARCHAR | False | <null> | False |
| 8 | Average Sesion Rating | DOUBLE | False | <null> | False |
| 9 | # Survey Responses | INTEGER | False | <null> | False |
| 10 | Please rate your overall experience with this session. | DOUBLE | False | <null> | False |
| 11 | Please rate the quality of the content. | DOUBLE | False | <null> | False |
| 12 | Please rate your satisfaction with the presenter. | DOUBLE | False | <null> | False |
[β¦]
+-----+--------------------------------------------------------+---------+---------+------------+-------+
Time: 0.011s
current_dbt.duckdb> describe rating_detail;
+-----+---------------+---------+---------+------------+-------+
| cid | name | type | notnull | dflt_value | pk |
+-----+---------------+---------+---------+------------+-------+
| 0 | sessionID | INTEGER | False | <null> | False |
| 1 | title | VARCHAR | False | <null> | False |
| 2 | Start Time | VARCHAR | False | <null> | False |
| 3 | Rating Type | VARCHAR | False | <null> | False |
| 4 | Rating Type_2 | VARCHAR | False | <null> | False |
| 5 | rating | INTEGER | False | <null> | False |
| 6 | Comment | VARCHAR | False | <null> | False |
| 7 | User ID | INTEGER | False | <null> | False |
| 8 | First | VARCHAR | False | <null> | False |
| 9 | Last | VARCHAR | False | <null> | False |
| 10 | Email | VARCHAR | False | <null> | False |
| 11 | Sponsor Share | VARCHAR | False | <null> | False |
| 12 | Account Type | VARCHAR | False | <null> | False |
| 13 | Attendee Type | VARCHAR | False | <null> | False |
+-----+---------------+---------+---------+------------+-------+
Time: 0.009s
current_dbt.duckdb>
Pretty nice! So letβs think now about what we want to do with this data.
Data Wrangling: The Spec π
There are several things I want to do with the data:
-
Create a single detail table of all rating comments and scores
-
Create a summary table of both rating and attendance data
-
Remove PII data of those who left ratings
-
Rename fields to remove spaces etc
-
Pivot the "Rating Type" / "rating" values into a set of columns.
In its current form it looks like this:
current_dbt.duckdb> select SessionID, "Rating Type", rating from rating_detail; +-----------+--------------------+--------+ | SessionID | Rating Type | rating | +-----------+--------------------+--------+ | 42 | Overall Experience | 5 | | 42 | Presenter | 5 | | 42 | Content | 4 | | 42 | Overall Experience | 5 | | 42 | Presenter | 5 | | 42 | Content | 5 | +-----------+--------------------+--------+ 6 rows in set Time: 0.009s
In the final table it would be better to pivot these into individual fields like this:
+------------+----------------+------------------+----------------+ | session_id | content_rating | presenter_rating | overall_rating | +------------+----------------+------------------+----------------+ | 42 | <null> | <null> | 5 | | 42 | <null> | 5 | <null> | | 42 | 4 | <null> | <null> | | 42 | <null> | <null> | 5 | | 42 | <null> | 5 | <null> | | 42 | 5 | <null> | <null> | +------------+----------------+------------------+----------------+ 6 rows in set Time: 0.009s
With the data structured like this analyses can be more easily run against the data.
-
Unify the identifier used for sessions - at the moment the two sets of data use
Session Code
andsessionID
which donβt relate and are sometimesnull
. The only common link is the title of the session itself.current_dbt.duckdb> select r.sessionID, s."Session Code", r.title from rating_detail r inner join session_scans s on r.title=s.name using sample 5; +-----------+--------------+-----------------------------------------------------------------------------------------------+ | sessionID | Session Code | title | +-----------+--------------+-----------------------------------------------------------------------------------------------+ | 140 | 50650015-1 | A Crash Course in Designing Messaging APIs | | 33 | 50650015-2 | You're Spiky and We Know It - Twilio's journey on Handling Data Spikes for Real-Time Alerting | | 141 | 50650011-7 | Bootiful Kafka: Get the Message! | | 139 | <null> | KEYNOTE: Apache Kafka: Past, Present, & Future | | 104 | 50650048-4 | Knock Knock, Who's There? Identifying Kafka Clients in a Multi-tenant Environment | +-----------+--------------+-----------------------------------------------------------------------------------------------+ 5 rows in set Time: 0.009s
-
Create a new field showing if an attendee who left a session rating was there in-person or not. The source data has
Attendee Type
field but this is more granular and exposes more data than weβd like to to the end analystcurrent_dbt.duckdb> select "Attendee type" , count(*) from main_seed_data.rating_detail group by "Attendee Type" order by 1; +--------------------+--------------+ | Attendee Type | count_star() | +--------------------+--------------+ | Employee | 126 | | General | 1334 | | Speaker | 298 | [β¦] | Virtual | 537 | +--------------------+--------------+ 15 rows in set Time: 0.008s
-
Exclude session data for mealtimes (whilst this data is important, itβs outside my scope of analysis)
-
Pivot the session track into a single field. Currently the data has a field for each track and a check in the appropriate one. Very spreadsheet-y, not very RDBMS-y:
current_dbt.duckdb> select * from main_seed_data.session_scans using sample 10; + [β¦] -+--------------+------------------+------------------------------+ | [β¦] | Kafka Summit | Modern Data Flow | Operations and Observability | + [β¦] -+--------------+------------------+------------------------------+ | [β¦] | x | <null> | x | | [β¦] | <null> | <null> | <null> | | [β¦] | x | x | <null> | | [β¦] | x | x | <null> | | [β¦] | <null> | <null> | x | | [β¦] | <null> | x | <null> | | [β¦] | <null> | <null> | x | | [β¦] | x | <null> | <null> | | [β¦] | <null> | x | <null> | | [β¦] | <null> | <null> | <null> | + [β¦] -+--------------+------------------+------------------------------+ 10 rows in set Time: 0.025s
Iβd rather narrow the table into a single
LIST
of track(s) for each session, something like:+ [β¦] -+----------------------------------------------------+ | [β¦] | Track | + [β¦] -+----------------------------------------------------+ | [β¦] | ['Kafka Summit','Operations and Observability'] | | [β¦] | ['Kafka Summit'] | | [β¦] | ['Kafka Summit'] | | [β¦] | ['Modern Data Flow'] | + [β¦] -+----------------------------------------------------+
My First Model π¨βπ π
Staging model #1: Rating Detail (stg_rating
) π
Following the pattern of the jaffle shop demo, Iβm going to use staging tables to tidy up the raw data to start with.
Weβll check the pattern works first with one table (rating_detail
) and then move on to the other.
In starting to write out the SQL I noticed a problem in my naming:
with source as (
select * from {{ ref('rating_detail')}}
)
Although the ref
here is to the seed data, it made me think about the database object names. If my source raw data is going to be loaded into a table called rating_detail
then itβs potentially going to get rather confusing. I want to either use a name prefix or perhaps a separate database catalog (schema) for this raw data that Iβve loaded. Checking the docs I found the seed configuration including an option to set the schema.
So Iβve added to my dbt_project.yml
the following:
seeds:
+schema: seed_data
I could drop the existing tables directly (just to keep things tidy), but in all honesty itβs quicker just to remove the database and let DuckDB create a new one when we re-run the seed command.
$ rm current_dbt.duckdb
$ dbt seed
13:26:03 Running with dbt=1.1.1
13:26:03 Unable to do partial parsing because a project config has changed
13:26:03 Found 2 models, 4 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
13:26:03
13:26:04 Concurrency: 1 threads (target='dev')
13:26:04
13:26:04 1 of 2 START seed file main_seed_data.rating_detail ............................ [RUN]
13:26:04 1 of 2 OK loaded seed file main_seed_data.rating_detail ........................ [INSERT 2416 in 0.54s]
13:26:04 2 of 2 START seed file main_seed_data.session_scans ............................ [RUN]
13:26:04 2 of 2 OK loaded seed file main_seed_data.session_scans ........................ [INSERT 163 in 0.11s]
13:26:04
13:26:04 Finished running 2 seeds in 0.84s.
13:26:04
13:26:04 Completed successfully
13:26:04
13:26:04 Done. PASS=2 WARN=0 ERROR=0 SKIP=0 TOTAL=2
Now my seed data is loaded into two tables in their own schema:
$ duckdb current_dbt.duckdb -c "select table_schema, table_name, table_type from information_schema.tables;"
ββββββββββββββββββ¬ββββββββββββββββ¬βββββββββββββ
β table_schema β table_name β table_type β
ββββββββββββββββββΌββββββββββββββββΌβββββββββββββ€
β main_seed_data β rating_detail β BASE TABLE β
β main_seed_data β session_scans β BASE TABLE β
ββββββββββββββββββ΄ββββββββββββββββ΄βββββββββββββ
So back to my staging model. Hereβs my first pass at the clean up of rating_detail
based on the relevant points of the spec above to implement at this stage.
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT title AS session_name,
"Rating Type" AS rating_type,
rating,
"comment" AS rating_comment,
"Attendee Type" AS attendee_type
-- Spec #7 Create a new field showing if attendee was in-person or not
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 AS virtual_attendee
-- Spec #3: Remove PII data of those who left ratings
FROM {{ ref('rating_detail') }}
)
SELECT *
FROM source_data
-- Spec #8: Exclude irrelevant sessions
WHERE session_name NOT IN ('Breakfast', 'Lunch', 'Registration')
Letβs compile it and see how it goes. Before I do this Iβm going to tear off the training wheels and remove the example models - we can do this for ourselves :-)
$ rm -rf models/example
$ dbt compile
14:24:11 Running with dbt=1.1.1
14:24:12 [WARNING]: Configuration paths exist in your dbt_project.yml file which do not apply to any resources.
There are 1 unused configuration paths:
- models.current_dbt.example
14:24:12 Found 1 model, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
14:24:12
14:24:12 Concurrency: 1 threads (target='dev')
14:24:12
14:24:12 Done.
A warning which weβll look at later, but for now it looks like the compile succeeded. Letβs check the output:
$ cat ./target/compiled/current_dbt/models/staging/stg_ratings.sql
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT title AS session_name,
"Rating Type" AS rating_type,
rating,
"comment" AS rating_comment,
"Attendee Type" AS attendee_type
-- Spec #7 Create a new field showing if attendee was in-person or not
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 AS virtual_attendee
-- Spec #3: Remove PII data of those who left ratings
FROM "main"."main_seed_data"."rating_detail"
)
SELECT *
FROM source_data
-- Spec #8: Exclude irrelevant sessions
WHERE session_name NOT IN ('Breakfast', 'Lunch', 'Registration')
Iβm not sure if the qualification of the schema looks right here FROM "main"."main_seed_data"."rating_detail"
but letβs worry about that when we need to. Which is right now, because Iβm going to try and run this model too. Over in the dbt_project.yml
Iβll tell it to create the staging model as a view (and in the process fix the warning above about the unused examples
path):
models:
current_dbt:
staging:
+materialized: view
With that set, letβs try running it. If all goes well, Iβll get a view created in DuckDB.
$ dbt run
14:27:41 Running with dbt=1.1.1
14:27:41 Unable to do partial parsing because a project config has changed
14:27:42 Found 1 model, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
14:27:42
14:27:42 Concurrency: 1 threads (target='dev')
14:27:42
14:27:42 1 of 1 START view model main.stg_ratings ....................................... [RUN]
14:27:42 1 of 1 ERROR creating view model main.stg_ratings .............................. [ERROR in 0.05s]
14:27:42
14:27:42 Finished running 1 view model in 0.24s.
14:27:42
14:27:42 Completed with 1 error and 0 warnings:
14:27:42
14:27:42 Runtime Error in model stg_ratings (models/staging/stg_ratings.sql)
14:27:42 Parser Error: syntax error at or near "CASE"
14:27:42 LINE 12: CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 AS virtual_attendee
14:27:42 -- Spec #3: Remove PII data of those who left ratings
14:27:42 FROM "main"."main_seed_data"."rating_detail"
14:27:42 )
14:27:42
14:27:42 SELECT *
14:27:42 FROM source_data
14:27:42 -- Spec #8: Exclude irrelevant sessions
14:27:42 WHERE session_name NOT IN ('Breakfast', 'Lunch', 'Registration')
14:27:42 );
14:27:42 ...
14:27:42 ^
14:27:42
14:27:42 Done. PASS=0 WARN=0 ERROR=1 SKIP=0 TOTAL=1
Well, all didnβt go well.
Runtime Error in model stg_ratings (models/staging/stg_ratings.sql)
Parser Error: syntax error at or near "CASE"
Hmmm. So it turns out that the compile will compile but not parse the SQL for validity. Rookie SQL mistake right here:
"Attendee Type" AS attendee_type
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 AS virtual_attendee
Can you see it? Or rather, not see it?
How about now?
-- ποΈπ
"Attendee Type" AS attendee_type,
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 AS virtual_attendee
With the errant comma put in its place after attendee_type
, and then subsequently the missing END
that the eagle-eyed amongst you will have spotted inserted in the CASE
statement, things look better:
"Attendee Type" AS attendee_type,
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 END AS virtual_attendee
and as if by magicβ¦
$ dbt run
14:55:57 Running with dbt=1.1.1
14:55:57 Found 1 model, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
14:55:57
14:55:57 Concurrency: 1 threads (target='dev')
14:55:57
14:55:57 1 of 1 START view model main.stg_ratings ....................................... [RUN]
14:55:57 1 of 1 OK created view model main.stg_ratings .................................. [OK in 0.08s]
14:55:57
14:55:57 Finished running 1 view model in 0.24s.
14:55:57
14:55:57 Completed successfully
14:55:57
14:55:57 Done. PASS=1 WARN=0 ERROR=0 SKIP=0 TOTAL=1
(turns out the schema qualification I was worrying about worked just fine)
Check it out!
$ duckdb current_dbt.duckdb -c "select table_schema, table_name, table_type from information_schema.tables;"
ββββββββββββββββββ¬ββββββββββββββββ¬βββββββββββββ
β table_schema β table_name β table_type β
ββββββββββββββββββΌββββββββββββββββΌβββββββββββββ€
β main_seed_data β session_scans β BASE TABLE β
β main_seed_data β rating_detail β BASE TABLE β
β main β stg_ratings β VIEW β
ββββββββββββββββββ΄ββββββββββββββββ΄βββββββββββββ
$ duckdb current_dbt.duckdb -c "select * from stg_ratings using sample 5;"
ββββββββββββββββββ¬βββββββββββββββββββββ¬βββββββββ¬ββββββββββββββββββββββ¬ββββββββββββββββββ¬βββββββββββββββββββ
β session_name β rating_type β rating β rating_comment β attendee_type β virtual_attendee β
ββββββββββββββββββΌβββββββββββββββββββββΌβββββββββΌββββββββββββββββββββββΌββββββββββββββββββΌβββββββββββββββββββ€
β Session x β Content β 4 β Need more cheetohs β Sponsor β 0 β
β Session y .. β Content β 3 β β General β 0 β
β Session z β Presenter β 4 β Great hair, ... β Sponsor β 0 β
β Session foo .. β Overall Experience β 5 β β Virtual β 1 β
β Session bar .. β Presenter β 5 β β General β 0 β
ββββββββββββββββββ΄βββββββββββββββββββββ΄βββββββββ΄ββββββββββββββββββββββ΄ββββββββββββββββββ΄βββββββββββββββββββ
(actual footage of me with my lockdown beard π )
The last thing we need to do is #5 in the spec aboveβββpivot the rating types into in individual columns, turning this:
+-----------+-----------+--------+
| SessionID |Rating Type| rating |
+-----------+-----------+--------+
| 42 | Overall | 5 |
| 42 | Presenter | 5 |
| 42 | Content | 4 |
| 42 | Overall | 5 |
| 42 | Presenter | 5 |
| 42 | Content | 5 |
+-----------+-----------+--------+
into this:
+------------+----------------+------------------+----------------+
| session_id | content_rating | presenter_rating | overall_rating |
+------------+----------------+------------------+----------------+
| 42 | <null> | <null> | 5 |
| 42 | <null> | 5 | <null> |
| 42 | 4 | <null> | <null> |
| 42 | <null> | <null> | 5 |
| 42 | <null> | 5 | <null> |
| 42 | 5 | <null> | <null> |
+------------+----------------+------------------+----------------+
For this Iβm going to try my hand at some Jinja since this feels like a great place for it. To start with, Iβll first get the unique set of values:
current_dbt.duckdb> select distinct rating_type from stg_ratings;
+--------------------+
| rating_type |
+--------------------+
| Overall Experience |
| Presenter |
| Content |
+--------------------+
3 rows in set
Time: 0.010s
and build this into a Jinja variable in the model:
{% set rating_types = ['Overall Experience','Presenter', 'Content'] %}
and then use this to build several CASE
statements:
-- Spec #5: Pivot rating type into individual columns
{% for r in rating_types -%}
CASE WHEN rating_type = '{{ r }}' THEN rating END AS {{ r.lower().replace(' ','_') }}_rating,
CASE WHEN rating_type = '{{ r }}' THEN "comment" END AS {{ r.lower().replace(' ','_') }}_comment,
{% endfor -%}
Note the use of .lower()
and .replace
to force the name to lowercase and replace spaces with underscores. Otherwise you end up with column names like "Overall Experience_comment"
instead of overall_experience_comment
.
Hereβs the finished model:
{% set rating_types = ['Overall Experience','Presenter', 'Content'] %}
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT TRIM(title) AS session_name,
-- Spec #5: Pivot rating type into individual columns
{% for r in rating_types -%}
CASE WHEN "Rating Type" = '{{ r }}' THEN rating END AS {{ r.lower().replace(' ','_') }}_rating,
CASE WHEN "Rating Type" = '{{ r }}' THEN "comment" END AS {{ r.lower().replace(' ','_') }}_comment,
{% endfor -%}
-- Spec #7 Create a new field showing if attendee was in-person or not
CASE WHEN "Attendee Type" = 'Virtual' THEN 1 ELSE 0 END AS virtual_attendee
-- Spec #3: Remove PII data of those who left ratings
FROM {{ ref('rating_detail') }}
)
SELECT *
FROM source_data
-- Spec #8: Exclude irrelevant sessions
WHERE session_name NOT IN ('Breakfast', 'Lunch', 'Registration')
Which creates a table that looks like this:
+-----+----------------------------+---------+
| cid | name | type |
+-----+----------------------------+---------+
| 0 | session_name | VARCHAR |
| 1 | overall_experience_rating | INTEGER |
| 2 | overall_experience_comment | VARCHAR |
| 3 | presenter_rating | INTEGER |
| 4 | presenter_comment | VARCHAR |
| 5 | content_rating | INTEGER |
| 6 | content_comment | VARCHAR |
| 7 | attendee_type | VARCHAR |
| 8 | virtual_attendee | INTEGER |
+-----+----------------------------+---------+
Staging model #2: Session Scans (stg_scans
) π
Letβs build the other staging model now. The only point of interest here is combining the numerous fields that represent all the tracks and have a value in them if the associated session was in that track.
The SQL pattern I want to replicate is this:
-
In a CTE (Common Table Expression), for each field, if itβs not
NULL
then return a single-entryLIST
with the name (not value) of the field -
Select from the CTE and use
LIST_CONCAT
to condense all theLIST
fields
If itβs easier to visualise it then hereβs a test dataset that mimics the source:
+--------+--------+
| A | B |
+--------+--------+
| <null> | X |
| X | <null> |
| X | X |
+--------+--------+
and hereβs the resulting transformation:
WITH X AS (SELECT A, B,
CASE WHEN A='X' THEN ['A'] END AS F0,
CASE WHEN B='X' THEN ['B'] END AS F1
FROM FOO)
SELECT LIST_CONCAT(F0, F1) AS COMBINED_FLAGS FROM X
+----------------+
| COMBINED_FLAGS |
+----------------+
| ['B'] |
| ['A'] |
| ['A', 'B'] |
+----------------+
Hereβs my stg_scans
model using this approach. Note also the use of loop.index
to create the required number of field aliases that can then be referenced in the subsequent SELECT
.
{% set tracks = ['Architectures You've Always Wondered About','Case Studies','Data Development Life Cycle','Developing Real-Time Applications','Event Streaming in Academia and Beyond','Fun and Geeky','Kafka Summit','Modern Data Flow','Operations and Observability','Panel','People & Culture','Real Time Analytics','Sponsored Session','Streaming Technologies'] %}
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT NAME AS session_name,
Speakers AS speakers,
scans AS scans,
"# Survey Responses" AS rating_ct,
-- Spec #9 Combine all track fields into a single summary
{% for t in tracks -%}
CASE WHEN t IS NOT NULL THEN ['t'] END
AS F{{ loop.index }},
{% endfor -%}
FROM {{ ref('session_scans') }}
)
SELECT session_name,
speakers,
scans,
rating_ct,
LIST_CONCAT(
{% for t in tracks -%}
F{{ loop.index }},
{% endfor -%}
) AS track
FROM source_data
Is it just me, or are you deeply suspicious when your code runs the first time of trying without error?
$ dbt run --select stg_scans
16:17:19 Running with dbt=1.1.1
16:17:19 Found 2 models, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
16:17:19
16:17:19 Concurrency: 1 threads (target='dev')
16:17:19
16:17:19 1 of 1 START view model main.stg_scans ......................................... [RUN]
16:17:19 1 of 1 OK created view model main.stg_scans .................................... [OK in 0.08s]
16:17:19
16:17:19 Finished running 1 view model in 0.20s.
16:17:20
16:17:20 Completed successfully
16:17:20
16:17:20 Done. PASS=1 WARN=0 ERROR=0 SKIP=0 TOTAL=1
and then you go to check the resulting viewβ¦ and itβs exactly that same as the one you just built with a different name?
current_dbt.duckdb> describe stg_scans;
+-----+------------------+---------+---------+------------+-------+
| cid | name | type | notnull | dflt_value | pk |
+-----+------------------+---------+---------+------------+-------+
| 0 | session_name | VARCHAR | False | <null> | False |
| 1 | rating_type | VARCHAR | False | <null> | False |
| 2 | rating | INTEGER | False | <null> | False |
| 3 | rating_comment | VARCHAR | False | <null> | False |
| 4 | attendee_type | VARCHAR | False | <null> | False |
| 5 | virtual_attendee | INTEGER | False | <null> | False |
+-----+------------------+---------+---------+------------+-------+
Time: 0.009s
β¦because you copied the source and didnβt save it so dbt was just running exactly the same as before but with a different name.
Letβs save our masterpiece and try actually running that instead:
$ dbt run --select stg_scans
16:22:33 Running with dbt=1.1.1
16:22:33 Encountered an error:
Compilation Error in model stg_scans (models/staging/stg_scans.sql)
expected token ',', got 've'
line 1
{% set tracks = ['Architectures You've Always Wondered About',
[β¦]
Phew - an error. I mean, thatβs a shame, but at least itβs running the code we wanted it to :)
The error was an unescaped quote, so letβs fix that and try again.
16:23:35 Completed with 1 error and 0 warnings:
16:23:35
16:23:35 Runtime Error in model stg_scans (models/staging/stg_scans.sql)
16:23:35 Parser Error: syntax error at or near ")"
16:23:35 LINE 62: ) AS track
16:23:35 ^
Not sure a clear error this time. Letβs check out the compiled SQL to see if our Jinja magic is working.
$ cat ./target/compiled/current_dbt/models/staging/stg_scans.sql
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT NAME AS session_name,
Speakers AS speakers,
scans AS scans,
"# Survey Responses" AS rating_ct,
-- Spec #9 Combine all track fields into a single summary
CASE WHEN t IS NOT NULL THEN ['t'] END
AS F1,
CASE WHEN t IS NOT NULL THEN ['t'] END
AS F2,
[β¦]
FROM "main"."main_seed_data"."session_scans"
)
SELECT session_name,
speakers,
scans,
rating_ct,
LIST_CONCAT(
F1,
F2,
[β¦]
) AS track
FROM source_data
So some of itβs working. The incrementing field name (F1
, F2
, etc), and the list iteration. However, the t
literal shouldnβt be there - and thatβs because I didnβt enclose it in the magic double curly braces {{ fun happens here }}
.
CASE WHEN t IS NOT NULL THEN ['t'] END
should be
CASE WHEN {{ t }} IS NOT NULL THEN ['{{ t }}'] END
Letβs compile that and see:
$ cat ./target/compiled/current_dbt/models/staging/stg_scans.sql
WITH source_data AS (
-- Spec #4: Rename fields to remove spaces etc
SELECT NAME AS session_name,
Speakers AS speakers,
scans AS scans,
"# Survey Responses" AS rating_ct,
-- Spec #9 Combine all track fields into a single summary
CASE WHEN Architectures You've Always Wondered About IS NOT NULL THEN ['Architectures You've Always Wondered About'] END
AS F1,
CASE WHEN Case Studies IS NOT NULL THEN ['Case Studies'] END
AS F2,
CASE WHEN Data Development Life Cycle IS NOT NULL THEN ['Data Development Life Cycle'] END
AS F3,
[β¦]
Weβre making progress! The field name needs double-quoting, and we need to work out how to escape the '
in some of the values. The former is simple enough, and the latter is solved with a quick visit to the dbt docs and their excellent search which hits escape_single_quotes
straight awayβ¦
β¦which turns out to not be so simple because the dbt version Iβm using (1.1.1) needs to be >=1.2 to use the function. For now Iβm going to omit the problematic track and worry about it at a later point if I have chance to figure out upgrading :)
So, having figured out the first Jinja problem (and hacked our way around it by fudging the data), letβs go back to the error that we had before:
Parser Error: syntax error at or near ")"
LINE 60: ) AS track
If we look at the compiled SQL, weβll see this:
[β¦]
SELECT session_name,
speakers,
scans,
rating_ct,
LIST_CONCAT(
F1,
F2,
[β¦]
F13,
) AS track
FROM source_data
Notice that trailing comma after the final field iteration (F13
)? Thatβs causing the error.
The problem comes from this bit of code:
LIST_CONCAT(
{% for t in tracks -%}
F{{ loop.index }},
{% endfor -%}
) AS track
The loop includes a field seperator ,
every iteration which is mostly what we wantβexcept we donβt want it on the final iteration. Letβs see if we can code around that by checking our index in the iteration (loop.index
) against the length of the list (tracks|length
):
LIST_CONCAT(
{% for t in tracks -%}
-- Literal If the current loop index Literal
-- | Loop index is not the last one THEN | end if
-- | | | | |
-- V\--------------/ \---------------------------------/V \---------/
F{{ loop.index }} {% if loop.index < tracks|length %}, {% endif %}
{% endfor -%}
) AS track
Now if we compile the model we can see a nice set of SQL:
LIST_CONCAT(
F1 ,
F2 ,
[β¦]
F12 ,
F13
) AS track
Weβre getting there, but still no dice when we run the model:
$ dbt run --select stg_scans
16:54:13 Running with dbt=1.1.1
16:54:14 Found 2 models, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0
metrics
16:54:14
16:54:14 Concurrency: 1 threads (target='dev')
16:54:14
16:54:14 1 of 1 START view model main.stg_scans ......................................... [RUN]
16:54:14 1 of 1 ERROR creating view model main.stg_scans ................................ [ERROR in 0.05s]
16:54:14
16:54:14 Finished running 1 view model in 0.21s.
16:54:14
16:54:14 Completed with 1 error and 0 warnings:
16:54:14
16:54:14 Runtime Error in model stg_scans (models/staging/stg_scans.sql)
16:54:14 Binder Error: No function matches the given name and argument types 'list_concat(VARCHAR[], VARCHAR[], VARCHAR[],
VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[], VARCHAR[])'. You might ne
ed to add explicit type casts.
16:54:14 Candidate functions:
16:54:14 list_concat(ANY[], ANY[]) -> ANY[]
16:54:14
16:54:14
16:54:14 Done. PASS=0 WARN=0 ERROR=1 SKIP=0 TOTAL=1
Turns out I mis-read the docs for LIST_CONCAT
β it concatenates two lists, not many. We can see this if I expand my test case from above:
current_dbt.duckdb> WITH X AS (SELECT A, B,
CASE WHEN A='X' THEN ['A'] END AS F0,
CASE WHEN B='X' THEN ['B'] END AS F1, CASE WHEN B='X' THEN ['B'] END AS F2
FROM FOO)
SELECT LIST_CONCAT(F0, F1, F2) AS COMBINED_FLAGS FROM X
Binder Error: No function matches the given name and argument types 'list_concat(VARCHAR[], VARCHAR[], VARCHAR[])'. You might need to add explicit type casts.
Candidate functions:
list_concat(ANY[], ANY[]) -> ANY[]
LINE 5: SELECT LIST_CONCAT(F0, F1, F2) AS COMBINED_FLAGS FROM X...
^
The solution is to stack the LIST_CONCAT
statements, as demonstrated here:
current_dbt.duckdb> WITH X AS (SELECT A, B,
CASE WHEN A='X' THEN ['A'] END AS F0,
CASE WHEN B='X' THEN ['B'] END AS F1,
CASE WHEN B='X' THEN ['B'] END AS F2
FROM FOO)
SELECT LIST_CONCAT(LIST_CONCAT(F0, F1), F2) AS COMBINED_FLAGS FROM X
+-----------------+
| COMBINED_FLAGS |
+-----------------+
| ['B', 'B'] |
| ['A'] |
| ['A', 'B', 'B'] |
+-----------------+
3 rows in set
Time: 0.009s
After a bit of fiddling hereβs the bit of the dbt model code to generate this necessary SQL:
[β¦]
SELECT [β¦],
-- LIST_CONCAT takes two parameters, so we're going to stack them.
-- Write a nested LIST_CONCAT for all but one occurance of the tracks
{% for x in range((tracks|length -1)) -%}
LIST_CONCAT(
{% endfor -%}
-- For every trackβ¦
{% for t in tracks -%}
-- Write out the field number
F{{ loop.index }}
-- Unless it's the first one, add a close parenthesis
{% if loop.index !=1 %}) {% endif %}
-- Unless it's the last one, add a comma
{% if loop.index < tracks|length %}, {% endif %}
{% endfor -%}
AS track
FROM source_data
Which compiles into this monstrosity (minus the whitespaces and verbose comments):
SELECT [β¦]
LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT ( LIST_CONCAT (
F1 , F2 ) , F3 ) , F4 ) , F5 ) , F6 ) , F7 ) , F8 ) , F9 ) , F10 ) , F11 ) , F12 ) , F13 )
AS track
FROM source_data
The resulting transformed data looks like this - exactly what we wanted, with a single field and zero or more instances of the Track value:
+-------------------------------------------------------+
| track |
+-------------------------------------------------------+
| ['Kafka Summit', 'Modern Data Flow'] |
| ['Panel'] |
| <null> |
| ['Kafka Summit', 'Streaming Technologies'] |
| ['Event Streaming in Academia and Beyond'] |
[β¦]
Over on the friendly DuckDB Discord group there were a couple of suggestions how this SQL might be written more effectively and neatly, including using list_filter()
with a lambda, or using list comprehension functionality which was added recently. I didnβt try either of these yet so let me know if you have done!
The other thing to say here is that the point of the Jinja templating is to make models reusable and flexible - but arguably that soup of {{
{%
(
etc above may not be as straightforward to maintain in the long run given a static data set as simply copy and pasting the SQL with the hard-coded values whilst the logic is fresh in oneβs head. Right tool, right job.
Staging model #3: Session IDs π
The last thing that I want to add to both staging tables is a surrogate key to represent the unique session (#6 in the spec list above). Thereβs a nice doc about surrogate keys on the dbt website itself. To do this Iβll create a utility staging table to generate the IDs across both sources (stg_scans
, stg_ratings
), and then use this in the subsequent join that Iβll do afterwards.
The two sources of data (scans and ratings) have a different number of sessions:
current_dbt.duckdb> select count (distinct session_name) from stg_scans;
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 157 |
+------------------------------+
1 row in set
Time: 0.009s
current_dbt.duckdb> select count (distinct session_name) from stg_ratings
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 123 |
+------------------------------+
1 row in set
Time: 0.008s
So stg_scans
has the most rows, and we can check which table(s) has unique sessions in:
current_dbt.duckdb> select session_name from stg_ratings
where session_name not in
(select session_name
from stg_scans);
0 rows in set
Time: 0.006s
current_dbt.duckdb> select session_name from stg_scans
where session_name not in
(select session_name
from stg_ratings);
117 rows in set
Time: 0.032s
This tells us that all sessions that are in stg_ratings
are also in stg_scans
, but stg_scans
has sessions that arenβt in stg_ratings
.
I made an error in my SQL above - the narrative below is still valid, but read on afterwards for a correction. |
Letβs try out creating a surrogate key using the md5
hash function.
By creating a UNION
across the two tables we should get a unique list of sessions. So long as the session has the same name, itβll have the same md5 value, and thus the same key value. Weβll try it out first for one session that we know is on both tables:
current_dbt.duckdb> select session_name
from stg_scans
where session_name in
(select session_name
from stg_ratings)
fetch first 1 row only;
+---------------------------------+
| session_name |
+---------------------------------+
| "Why Wait?" Real-time Ingestion |
+---------------------------------+
1 row in set
Time: 0.009s
current_dbt.duckdb> SELECT 'stg_ratings' AS source,
MD5(session_name) AS session_id,
session_name
FROM stg_ratings
WHERE session_name = '"Why Wait?" Real-time Ingestion'
UNION
SELECT 'stg_scans' AS source,
MD5(session_name) AS session_id,
session_name
FROM stg_scans
WHERE session_name = '"Why Wait?" Real-time Ingestion';
+-------------+----------------------------------+---------------------------------+
| source | session_id | session_name |
+-------------+----------------------------------+---------------------------------+
| stg_ratings | 43f10e52cd2f23100571189beee23450 | "Why Wait?" Real-time Ingestion |
| stg_scans | 43f10e52cd2f23100571189beee23450 | "Why Wait?" Real-time Ingestion |
+-------------+----------------------------------+---------------------------------+
2 rows in set
Time: 0.011s
Note Iβve created a field called source
just to show which table the value is coming from. If I remove that then the UNION
de-duplicates the remaining content to give us just the one value:
current_dbt.duckdb> SELECT MD5(session_name) AS session_id,
session_name
FROM stg_ratings
WHERE session_name = '"Why Wait?" Real-time Ingestion'
UNION
SELECT MD5(session_name) AS session_id,
session_name
FROM stg_scans
WHERE session_name = '"Why Wait?" Real-time Ingestion';
+----------------------------------+---------------------------------+
| session_id | session_name |
+----------------------------------+---------------------------------+
| 43f10e52cd2f23100571189beee23450 | "Why Wait?" Real-time Ingestion |
+----------------------------------+---------------------------------+
1 row in set
Time: 0.010s
Letβs check that it works where a session is only in one source table and not the other:
current_dbt.duckdb> select session_name
from stg_scans
where session_name not in
(select session_name
from stg_ratings)
fetch first 1 row only;
+----------------------------------------------------------------------------------+
| session_name |
+----------------------------------------------------------------------------------+
| A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia |
+----------------------------------------------------------------------------------+
1 row in set
Time: 0.009s
current_dbt.duckdb> SELECT 'stg_ratings' AS source,
MD5(session_name) AS session_id,
session_name
FROM stg_ratings
WHERE session_name = 'A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia'
UNION
SELECT 'stg_scans' AS source,
MD5(session_name) AS session_id,
session_name
FROM stg_scans
WHERE session_name = 'A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia';
+-------------+----------------------------------+---------------------------------------------------------------------------------+
| source | session_id | session_name |
+-------------+----------------------------------+---------------------------------------------------------------------------------+
| stg_ratings | a8b8ea81d950cee37061756ddebc67a0 | A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia |
+-------------+----------------------------------+---------------------------------------------------------------------------------+
1 row in set
Time: 0.012s
Combining the two test session names gives us this:
current_dbt.duckdb> SELECT MD5(session_name) AS session_id,
session_name
FROM stg_ratings
WHERE session_name IN ('"Why Wait?" Real-time Ingestion', 'A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia')
UNION
SELECT MD5(session_name) AS session_id,
session_name
FROM stg_scans
WHERE session_name IN ('"Why Wait?" Real-time Ingestion', 'A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia')
+----------------------------------+---------------------------------------------------------------------------------+
| session_id | session_name |
+----------------------------------+---------------------------------------------------------------------------------+
| 43f10e52cd2f23100571189beee23450 | "Why Wait?" Real-time Ingestion |
| a8b8ea81d950cee37061756ddebc67a0 | A Systematic Literature Review and Meta-Analysis of Event Streaming in Academia |
+----------------------------------+---------------------------------------------------------------------------------+
2 rows in set
Time: 0.012s
Letβs build that into a model called stg_sessionid
in dbt. This will be the driving model for the joins weβll be doing afterwards. The data above shows that in this case we could use stg_scans
(because it has all of the sessions) but Iβd rather do it properly and cater for the chance we have unique sessions on either side of the join.
WITH source_data AS (
-- Spec #6: Create a unique ID for each session
SELECT md5(session_name) AS session_id,
session_name
FROM {{ ref('stg_ratings') }}
UNION
SELECT md5(session_name) AS session_id,
session_name
FROM {{ ref('stg_scans') }}
)
SELECT *
FROM source_data
When I do dbt run
now youβll notice that it knows automagically to build stg_ratings
and stg_scans
before stg_sessionid
because the latter depends on the first two.
$ dbt run
08:32:55 Running with dbt=1.1.1
08:32:55 Found 3 models, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
08:32:55
08:32:55 Concurrency: 1 threads (target='dev')
08:32:55
08:32:55 1 of 3 START view model main.stg_ratings ....................................... [RUN]
08:32:55 1 of 3 OK created view model main.stg_ratings .................................. [OK in 0.07s]
08:32:55 2 of 3 START view model main.stg_scans ......................................... [RUN]
08:32:55 2 of 3 OK created view model main.stg_scans .................................... [OK in 0.04s]
08:32:55 3 of 3 START view model main.stg_sessionid ..................................... [RUN]
08:32:55 3 of 3 OK created view model main.stg_sessionid ................................ [OK in 0.07s]
08:32:55
08:32:55 Finished running 3 view models in 0.30s.
08:32:55
08:32:55 Completed successfully
08:32:55
08:32:55 Done. PASS=3 WARN=0 ERROR=0 SKIP=0 TOTAL=3
BUTβ¦ whatβs this? Our shiny new table (well, technically itβs a view) shows a number Iβm not expecting. Instead of 157 (the number of unique sessions in stg_ratings
seen above), itβs 241.
current_dbt.duckdb> select count(*) from stg_sessionid;
+--------------+
| count_star() |
+--------------+
| 241 |
+--------------+
1 row in set
Time: 0.009s
A debugging tangent π
If youβre just here for the tl;dr, or youβve already spotted the error in my SQL above then feel free to skip ahead. But thereβs something up with the SQL Iβve written and here Iβm going to work it through to see what.
Problem statement: two sets of data that I believe should have a combined unique count of 157 are resulting in a view that returns a unique count of 241.
Here is the unique count of data for the two data sets:
current_dbt.duckdb> select 'stg_scans' as source_table, count(distinct session_name) from stg_scans
union select 'stg_ratings' as source_table, count(distinct session_name) from stg_ratings ;
+--------------+------------------------------+
| source_table | count(DISTINCT session_name) |
+--------------+------------------------------+
| stg_scans | 157 |
| stg_ratings | 123 |
+--------------+------------------------------+
2 rows in set
Time: 0.011s
Of the 157 unique session_name
values in stg_scans
, 117 are not in stg_ratings
whilst 40 are:
current_dbt.duckdb> select count(distinct session_name) from stg_scans
where session_name not in
(select session_name
from stg_ratings)
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 117 |
+------------------------------+
1 row in set
Time: 0.011s
current_dbt.duckdb> select count(distinct session_name) from stg_scans
where session_name in
(select session_name
from stg_ratings)
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 40 |
+------------------------------+
1 row in set
Time: 0.010s
In reverse, of the the 123
unique session_name
values in stg_ratings
, 40 are also in stg_scans
(which matches the above), and 0 arenβtβ¦ this is getting a bit weird
current_dbt.duckdb> select count(distinct session_name) from stg_ratings
where session_name in
(select session_name
from stg_scans)
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 40 |
+------------------------------+
1 row in set
Time: 0.010s
current_dbt.duckdb> select count(distinct session_name) from stg_ratings
where session_name not in
(select session_name
from stg_scans)
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 0 |
+------------------------------+
1 row in set
Time: 0.009s
Surely if there are zero in stg_ratings
that are not in stg_scans
then by definition they should all be in stg_scans
(rather than just 40 or the 123 unique values).
Letβs look at this logically. Weβre talking about a Venn diagram in which two sets overlap partially. We can export the data:
$ duckdb current_dbt.duckdb -noheader -list -c 'select distinct session_name from stg_scans order by 1' > /tmp/scans.txt
$ duckdb current_dbt.duckdb -noheader -list -c 'select distinct session_name from stg_ratings order by 1' > /tmp/ratings.txt
and then drop the two resulting text files into a neat tool that I found to visualise the unique session names and the relationship between the two sets:
The tool usefully shows the resulting sets, and the four stg_ratings
sessions shown are:
Apache Kafka with Spark Structured Streaming and Beyond: Building Real-Time Data Processing and Analytics with Databricks
Data Streaming Celebration
Intersectional Happy Hour
Unofficial 5K Fun Run
So letβs see if we can track those down, taking just one as an example. Itβs definitely in stg_ratings
:
current_dbt.duckdb> select distinct session_name from stg_ratings
where session_name = 'Unofficial 5K Fun Run';
+-----------------------+
| session_name |
+-----------------------+
| Unofficial 5K Fun Run |
+-----------------------+
1 row in set
Time: 0.007s
And itβs definitely not in stg_scans
:
current_dbt.duckdb> select distinct session_name from stg_scans
where session_name = 'Unofficial 5K Fun Run';
0 rows in set
Time: 0.001s
So whatβs up with my subselect and not in
logic that means itβs not being returned?
ποΈ π€¦ββοΈ It turns out my SQL-foo is a tad rusty.
The subquery documentation on DuckDB is nice and clearly written - what I need is a correlated subquery
current_dbt.duckdb> select distinct session_name from stg_ratings r
where session_name = 'Unofficial 5K Fun Run'
and session_name not in
(select s.session_name
from stg_scans s
where s.session_name=r.session_name);
+-----------------------+
| session_name |
+-----------------------+
| Unofficial 5K Fun Run |
+-----------------------+
1 row in set
Time: 0.010s
Letβs test it a step further. Based on the above tool (since I donβt trust my SQL logic, clearly for good reasons) Iβve got three sessions that Iβll use for testing:
-
Only in
stg_scans
:Data Streaming: The Paths Taken
-
In both:
Advancing Apache NiFi Framework Security
-
Only in
stg_ratings
:Unofficial 5K Fun Run
So with those in the query amended to use a correlated subquery gives us this view of sessions that are only in stg_ratings
:
current_dbt.duckdb> select distinct session_name from stg_ratings r
where session_name in ( 'Data Streaming: The Paths Taken',
'Advancing Apache NiFi Framework Security',
'Unofficial 5K Fun Run' )
and session_name not in
(select s.session_name
from stg_scans s where s.session_name=r.session_name);
+------------------------------------------+
| session_name |
+------------------------------------------+
| Advancing Apache NiFi Framework Security |
| Unofficial 5K Fun Run |
+------------------------------------------+
2 rows in set
Time: 0.010s
current_dbt.duckdb>
β¦which is not what we expected. The Advancing Apache NiFi Framework Security
session is supposedly in both tables. Letβs check:
current_dbt.duckdb> select distinct session_name from stg_ratings
where session_name = 'Advancing Apache NiFi Framework Security';
+------------------------------------------+
| session_name |
+------------------------------------------+
| Advancing Apache NiFi Framework Security |
+------------------------------------------+
1 row in set
Time: 0.007s
current_dbt.duckdb> select distinct session_name from stg_scans
where session_name = 'Advancing Apache NiFi Framework Security';
0 rows in set
Time: 0.001s
Hmmm π€π€π€π€
What about this:
current_dbt.duckdb> select distinct session_name from stg_scans
where session_name like '%NiFi%';
+-------------------------------------------+
| session_name |
+-------------------------------------------+
| Advancing Apache NiFi Framework Security |
+-------------------------------------------+
1 row in set
Time: 0.007s
π‘Ahhhh (or should that be "arrgghhh"?) Either way - we have a bit of progress. If you look closely you can see that thereβs an errant whitespace (or at least unprintable character) at the end of the session name.
Letβs try it like this:
current_dbt.duckdb> select distinct session_name from stg_scans
where trim(session_name) = 'Advancing Apache NiFi Framework Security';
+-------------------------------------------+
| session_name |
+-------------------------------------------+
| Advancing Apache NiFi Framework Security |
+-------------------------------------------+
1 row in set
Time: 0.008s
OK, so trim
helps here. Applying this to the above query gives us this:
current_dbt.duckdb> select distinct session_name from stg_ratings r
where session_name in ( 'Data Streaming: The Paths Taken',
'Advancing Apache NiFi Framework Security',
'Unofficial 5K Fun Run' )
and trim(session_name) not in
(select trim(s.session_name)
from stg_scans s where trim(s.session_name)=trim(r.session_name));
+-----------------------+
| session_name |
+-----------------------+
| Unofficial 5K Fun Run |
+-----------------------+
1 row in set
Time: 0.013s
Alrighty then! This is what we expected for these three test values.
Instead of jamming trim
throughout our queries, letβs clean the data further up the pipeline, and amend the two staging models upstream to include it once. Hereβs where you start to really appreciate the elegance of dbt. By defining models once itβs easy to put the logic in the right place instead of bodging it in subsequent queries.
$ git diff models/staging/stg_ratings.sql
[β¦]
- SELECT title AS session_name,
+ SELECT TRIM(title) AS session_name,
$ git diff models/staging/stg_scans.sql
[β¦]
- SELECT NAME AS session_name,
+ SELECT TRIM(name) AS session_name,
After making that change we do a dbt run
and re-run the test query above to see how things look now. Iβm going to add three more test session values too, one for each category (in one, in the other, in both)
current_dbt.duckdb> -- Two sessions only in stg_ratings
select distinct session_name from stg_ratings r
where session_name in ( 'Data Streaming: The Paths Taken', 'Streaming Use Cases and Trends',
'Advancing Apache NiFi Framework Security', 'Bootiful Kafka: Get the Message!',
'Unofficial 5K Fun Run', 'Data Streaming Celebration' )
-- only in the first set
-- ποΈ ποΈ
and session_name not in (select s.session_name from stg_scans s where s.session_name=r.session_name);
+----------------------------+
| session_name |
+----------------------------+
| Data Streaming Celebration |
| Unofficial 5K Fun Run |
+----------------------------+
2 rows in set
Time: 0.009s
current_dbt.duckdb> -- Two sessions in both stg_ratings and stg_scans
select distinct session_name from stg_ratings r
where session_name in ( 'Data Streaming: The Paths Taken', 'Streaming Use Cases and Trends',
'Advancing Apache NiFi Framework Security', 'Bootiful Kafka: Get the Message!',
'Unofficial 5K Fun Run', 'Data Streaming Celebration' )
-- in both sets ποΈ
and session_name in (select s.session_name from stg_scans s where s.session_name=r.session_name);
+------------------------------------------+
| session_name |
+------------------------------------------+
| Advancing Apache NiFi Framework Security |
| Bootiful Kafka: Get the Message! |
+------------------------------------------+
2 rows in set
Time: 0.009s
current_dbt.duckdb> -- Two sessions in only stg_scans
select distinct session_name from stg_scans s
where session_name in ( 'Data Streaming: The Paths Taken', 'Streaming Use Cases and Trends',
'Advancing Apache NiFi Framework Security', 'Bootiful Kafka: Get the Message!',
'Unofficial 5K Fun Run', 'Data Streaming Celebration' )
-- only in the first set
-- ποΈ ποΈ
and session_name not in (select r.session_name from stg_ratings r where r.session_name=s.session_name);
+---------------------------------+
| session_name |
+---------------------------------+
| Data Streaming: The Paths Taken |
| Streaming Use Cases and Trends |
+---------------------------------+
2 rows in set
Time: 0.015s
OK, weβre looking good. Letβs try it without the predicates. There should be four rows returned for sessions only in stg_ratings
:
current_dbt.duckdb> select distinct session_name from stg_ratings r
-- only in the first set
-- ποΈ ποΈ
where session_name not in (select s.session_name from stg_scans s where s.session_name=r.session_name);
+---------------------------------------------------------------------------------------------------------------------------+
| session_name |
+---------------------------------------------------------------------------------------------------------------------------+
| Apache Kafka with Spark Structured Streaming and Beyond: Building Real-Time Data Processing and Analytics with Databricks |
| Data Streaming Celebration |
| Unofficial 5K Fun Run |
| Intersectional Happy Hour |
+---------------------------------------------------------------------------------------------------------------------------+
4 rows in set
Time: 0.013s
π₯π₯π₯π₯
Remember that Venn diagram above? This one:
Letβs check those numbers against our newly-fixed SQL and data:
current_dbt.duckdb> -- In ONLY stg_scans
select COUNT(distinct session_name) from stg_scans s
-- only in the first set
-- ποΈ ποΈ
where session_name not in (select r.session_name from stg_ratings r where r.session_name=s.session_name);
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 38 |
+------------------------------+
1 row in set
Time: 0.012s
current_dbt.duckdb> -- In BOTH stg_ratings and stg_scans
select COUNT(distinct session_name) from stg_ratings r
-- in BOTH sets
-- ποΈ
where session_name in (select s.session_name from stg_scans s where s.session_name=r.session_name);
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 119 |
+------------------------------+
1 row in set
Time: 0.014s
current_dbt.duckdb> -- In ONLY stg_ratings
select COUNT(distinct session_name) from stg_ratings r
-- only in the first set
-- ποΈ ποΈ
where session_name not in (select s.session_name from stg_scans s where s.session_name=r.session_name);
+------------------------------+
| count(DISTINCT session_name) |
+------------------------------+
| 4 |
+------------------------------+
1 row in set
Time: 0.012s
Normal service has been resumedβ¦ π
If you stayed with me on that tangentβ¦ bravo. If you didnβt, thatβs understandable. Itβs like being at a conference where the speaker doing a demo "Um"s an "Ah"s and "It was working when I tried it before" through an error and everyone else gets restless and goes to check Twitter.
So I made a mistake in my initial analysis and numbers. Instead of 157 unique sessions there should be 38 + 119 + 4 = 161. Letβs see what the fix we put in for whitespace (trim
) has done to the results of stg_sessionid
:
current_dbt.duckdb> select count(*) from stg_sessionid;
+--------------+
| count_star() |
+--------------+
| 162 |
+--------------+
1 row in set
Time: 0.012s
162! Itβs almost 161! But not quite!
How about this, on a hunch:
current_dbt.duckdb> select count(*) from stg_sessionid where session_name is not null;
+--------------+
| count_star() |
+--------------+
| 161 |
+--------------+
1 row in set
Time: 0.013s
There we have it ladies and gentlemen! The number that we were (eventually) expecting. Letβs check the data first to make sure weβve not got a data issue that we need to fix upstream (i.e. valid data but no session name):
current_dbt.duckdb> select * from stg_scans where session_name is null;
+--------------+----------+--------+-----------+--------+
| session_name | speakers | scans | rating_ct | track |
+--------------+----------+--------+-----------+--------+
| <null> | <null> | <null> | <null> | <null> |
| <null> | <null> | <null> | <null> | <null> |
+--------------+----------+--------+-----------+--------+
2 rows in set
Time: 0.012s
That looks good to remove, so weβll tweak the stg_sessionid
model to exclude NULL
sessions:
diff --git a/current_dbt/models/staging/stg_sessionid.sql b/current_dbt/models/staging/stg_sessionid.sql
index 1eb3743..5fbe8de 100644
--- a/current_dbt/models/staging/stg_sessionid.sql
+++ b/current_dbt/models/staging/stg_sessionid.sql
@@ -11,3 +11,4 @@ WITH source_data AS (
SELECT *
FROM source_data
+WHERE session_name IS NOT NULL
After re-running all the models, the stg_sessionid
is showing exactly the right count:
current_dbt.duckdb> select count(*) from stg_sessionid;
+--------------+
| count_star() |
+--------------+
| 161 |
+--------------+
1 row in set
Time: 0.013s
Staging model 3.5 - Sessions π
Itβs probably going to be more useful to have a unique list of sessions and their associated attributes (speaker, etc), so Iβm going to amend the stg_sessionid
to be stg_session
and add these in. There are couple of factual attributes (number of scans, number of ratings) which are arguably facts, but Iβll worry about that another day. For now itβs all at the same grain (session) and so makes sense in the same place:
WITH source_data AS (
-- Spec #6: Create a unique ID for each session
SELECT md5(session_name) AS session_id,
session_name
FROM {{ ref('stg_ratings') }}
UNION
SELECT md5(session_name) AS session_id,
session_name
FROM {{ ref('stg_scans') }}
)
SELECT src.session_id,
src.session_name,
sc.speakers,
sc.track,
SUM(sc.scans) AS scans,
SUM(sc.rating_ct) AS rating_ct
FROM src.source_data src
LEFT OUTER JOIN
{{ ref('stg_scans') }} sc
ON src.session_name = sc.session_name
WHERE src.session_name IS NOT NULL
GROUP BY src.session_id,
src.session_name,
sc.speakers,
sc.track
Youβll notice a SUM
and GROUP BY
in there, because some sessions had multiple scan and rating data which needed rolling up. This also highlighted a type error in the stg_scans
which I went back and fixed in the model (instead of just kludging it in-place here):
diff --git a/current_dbt/models/staging/stg_scans.sql b/current_dbt/models/staging/stg_scans.sql
[β¦]
- scans AS scans,
+ TRY_CAST(scans AS INT) AS scans,
The finished result - Model 1: Session Rating Detail π
For this, weβll just instantiate the session rating detail that we just built in staging, joined with the session dimension data:
SELECT s.session_id,
s.session_name,
s.speakers,
r.virtual_attendee,
r.overall_experience_rating,
r.presenter_rating,
r.content_rating,
r.overall_experience_comment,
r.presenter_comment,
r.content_comment
FROM {{ ref('stg_ratings')}} r
LEFT JOIN
{{ ref('stg_session') }} s
ON s.session_name = r.session_name
When we run the whole project we can see again that dbt just figures out the dependencies so that everythingβs built in the right order:
$ dbt run
11:43:23 Running with dbt=1.1.1
11:43:23 Found 4 models, 0 tests, 0 snapshots, 0 analyses, 167 macros, 0 operations, 2 seed files, 0 sources, 0 exposures, 0 metrics
11:43:23
11:43:23 Concurrency: 1 threads (target='dev')
11:43:23
11:43:23 1 of 4 START view model main.stg_ratings ....................................... [RUN]
11:43:23 1 of 4 OK created view model main.stg_ratings .................................. [OK in 0.07s]
11:43:23 2 of 4 START view model main.stg_scans ......................................... [RUN]
11:43:23 2 of 4 OK created view model main.stg_scans .................................... [OK in 0.07s]
11:43:23 3 of 4 START view model main.stg_session ....................................... [RUN]
11:43:23 3 of 4 OK created view model main.stg_session .................................. [OK in 0.04s]
11:43:23 4 of 4 START table model main.session_ratings_detail ........................... [RUN]
11:43:23 4 of 4 OK created table model main.session_ratings_detail ...................... [OK in 0.08s]
11:43:23
11:43:23 Finished running 3 view models, 1 table model in 0.41s.
11:43:23
11:43:23 Completed successfully
11:43:23
11:43:23 Done. PASS=4 WARN=0 ERROR=0 SKIP=0 TOTAL=4
Over in DuckDB we can see our seed data, three staging views, and a tableβ¦
$ duckdb current_dbt.duckdb -c "select table_schema, table_name, table_type from information_schema.tables;"
ββββββββββββββββββ¬βββββββββββββββββββββββββ¬βββββββββββββ
β table_schema β table_name β table_type β
ββββββββββββββββββΌβββββββββββββββββββββββββΌβββββββββββββ€
β main_seed_data β session_scans β BASE TABLE β
β main_seed_data β rating_detail β BASE TABLE β
β main β stg_session β VIEW β
β main β stg_ratings β VIEW β
β main β stg_scans β VIEW β
β main β session_ratings_detail β VIEW β
ββββββββββββββββββ΄βββββββββββββββββββββββββ΄βββββββββββββ
Except - our finished table (session_ratings_detail
) is still a VIEW. Over in dbt_project.yml
I need to tell dbt to actually materialise it:
[β¦]
models:
current_dbt:
materialized: table
staging:
+materialized: view
Which has the desired effect:
$ duckdb current_dbt.duckdb -c "select table_schema, table_name, table_type from information_schema.tables;"
ββββββββββββββββββ¬βββββββββββββββββββββββββ¬βββββββββββββ
β table_schema β table_name β table_type β
ββββββββββββββββββΌβββββββββββββββββββββββββΌβββββββββββββ€
β main_seed_data β session_scans β BASE TABLE β
β main_seed_data β rating_detail β BASE TABLE β
β main β session_ratings_detail β BASE TABLE β
β main β stg_session β VIEW β
β main β stg_ratings β VIEW β
β main β stg_scans β VIEW β
ββββββββββββββββββ΄βββββββββββββββββββββββββ΄βββββββββββββ
And a sample of the finished data:
current_dbt.duckdb> select session_id, overall_experience_comment, presenter_rating, content_rating from session_ratings_detail;
+----------------------------------+----------------------------+------------------+----------------+
| session_id | overall_experience_comment | presenter_rating | content_rating |
+----------------------------------+----------------------------+------------------+----------------+
| 2487f06e9800cbe86e35df66d8df2e27 | I want more Flink! | <null> | <null> |
| 2487f06e9800cbe86e35df66d8df2e27 | <null> | 4 | <null> |
| 2487f06e9800cbe86e35df66d8df2e27 | <null> | <null> | 4 |
| 2487f06e9800cbe86e35df66d8df2e27 | <null> | 5 | <null> |
| 2487f06e9800cbe86e35df66d8df2e27 | <null> | <null> | 5 |
The finished result - Model 2: Session Summary π
The breakdown of individual ratings data as we just created is useful for deep-dive analysis, but whatβs going to be useful overall is a summary of each sessionβs data, which is what weβll create with the sessions.sql
model. Check out the explanation below for notes.
{% set rating_areas = ['overall_experience','presenter', 'content'] %}
{% set rating_types = ['rating','comment'] %}
WITH ratings_agg AS (
SELECT session_id,
{% for a in rating_areas -%}
{% for r in rating_types -%}
LIST_SORT(
LIST({{a}}_{{r}}),
'DESC') AS {{a}}_{{r}},
{% endfor -%}
{% endfor -%}
FROM {{ ref('session_ratings_detail')}}
GROUP BY session_id
)
SELECT s.session_id,
s.session_name,
s.speakers,
s.track,
s.scans,
{% for a in rating_areas -%}
LIST_FILTER({{a}}_rating,x->x IS NOT NULL) AS {{a}}_rating_detail,
LIST_MEDIAN({{a}}_rating) AS {{a}}_rating_median,
LIST_FILTER({{a}}_comment,x->x IS NOT NULL) AS {{a}}_comments,
{% endfor -%}
s.rating_ct
FROM {{ ref('stg_session')}} s
LEFT JOIN
ratings_agg r
ON s.session_id = r.session_id
The main point of interest in the model here is compressing the above session_ratings_detail
using the LIST
data type and subsequent filter, aggregate, and sort functions.
-
Build a
LIST
as an aggregate:SELECT LIST(content_rating) FROM session_ratings_detail GROUP BY session_id;
Note that the
LIST
gets an entry even if thereβs no value:+----------------------------------------------------------+ | list(content_rating) | +----------------------------------------------------------+ |[None, None, 4, None, None, None, None, 5, None, None, 3] |
-
Sort the list with
LIST_SORT
:SELECT LIST_SORT(LIST(content_rating),'DESC') FROM session_ratings_detail GROUP BY session_id;
+-----------------------------------------------------------+ | list_sort(list(content_rating), 'DESC') | +-----------------------------------------------------------+ | [None, None, None, None, None, None, None, None, 5, 4, 3] | +-----------------------------------------------------------+
-
Filter the list using
LIST_FILTER
and a LambdaWITH agg AS (SELECT session_id, LIST_SORT(LIST(content_rating),'DESC') as my_list FROM session_ratings_detail GROUP BY session_id) SELECT LIST_FILTER(my_list, returned_field -> returned_field IS NOT NULL) FROM agg;
+----------------------------------------------------------------------+ | list_filter(my_list, returned_field -> (returned_field IS NOT NULL)) | +----------------------------------------------------------------------+ | [5, 4, 3] |
-
Aggregate the contents of the list using
LIST_AGGREGATE
which provides a list of rewrites - youβll see in the following example both return the same result:WITH agg AS (SELECT session_id, LIST_SORT(LIST(content_rating),'DESC') as my_list FROM session_ratings_detail GROUP BY session_id) SELECT my_list, LIST_AGGREGATE(my_list, 'median'), LIST_MEDIAN(my_list) FROM agg;
The resulting data looks like this:
+-----------------------------------------------------------+-----------------------------------+----------------------+ | my_list | list_aggregate(my_list, 'median') | list_median(my_list) | +-----------------------------------------------------------+-----------------------------------+----------------------+ | [None, None, None, None, None, None, None, None, 5, 4, 3] | 4.0 | 4.0 |
The resulting sessions
table looks like this:
current_dbt.duckdb> select *
from sessions
+----------------------------------+---------------------------------------+-------------+-------------------------------------------------+-------+----------------------------------+----------------------------------+-----------------------------------------------------------------+--------------------------+-------------------------+----------------------+--------------------------+-----------------------+------------------+-----------+
| session_id | session_name | speakers | track | scans | overall_experience_rating_detail | overall_experience_rating_median | overall_experience_comments | presenter_rating_detail | presenter_rating_median | presenter_comments | content_rating_detail | content_rating_median | content_comments | rating_ct |
+----------------------------------+---------------------------------------+-------------+-------------------------------------------------+-------+----------------------------------+----------------------------------+-----------------------------------------------------------------+--------------------------+-------------------------+----------------------+--------------------------+-----------------------+------------------+-----------+
| 4eac7c6d30952b9a20f216c897a5a5ef | Never Gonna Give you Up | Rick Astley | ['Data Development Life Cycle', 'Kafka Summit'] | 107 | [5, 5, 5, 5, 5, 4, 4, 3] | 5.0 | ['Very informative and hope to bring ideas back to my company'] | [5, 5, 5, 5, 5, 5, 5, 3] | 5.0 | ['Very well spoken'] | [5, 5, 5, 5, 5, 4, 4, 3] | 5.0 | [] | 24 |
+----------------------------------+---------------------------------------+-------------+-------------------------------------------------+-------+----------------------------------+----------------------------------+-----------------------------------------------------------------+--------------------------+-------------------------+----------------------+--------------------------+-----------------------+------------------+-----------+
Wrapping up π
With the seed, staging, and main models built, Iβve got a project that transforms two raw CSV files into a nicely (-ish) modelled set of data. Iβve not touched things like incremental loads, schema.yml
definitions, docs, tests, snapshots, and all the rest of it. But I have picked up an appreciation for what dbt can do, and why there is such a fuss about it.
Could I have written this all myself without dbt? Sure. Would I have wanted to? Perhaps. Would it have been so easy to easily go back and change definitions of staging tables as I realised Iβd missed columns, mis-typed data, etc? Definitely not. Would it have been possible to give a list of values and iterate over them to dynamically build SQL? I guess, but coding anything other than SQL really isnβt my bag - "just enough" coding here seems the perfect amount, sticking to the declarative power of SQL for the vast bulk of transformation work.
Comments? π
This is my first proper outing with dbt, other than following along someone elseβs code previously. Iβd love to hear any feedback on my approach with it - what did I do wrong? What wasnβt dbtonic? What other features should I dig into? Hit me up on twitter or LinkedIn π
Data Engineering in 2022 π
-
Query & Transformation Engines [TODO]
