After a week’s holiday ("vacation", for y’all in the US) without a glance at anything work-related, what joy to return and find that the DuckDB folk have been busy, not only with the recent 1.3.0 DuckDB release, but also a brand new project called DuckLake.

Here are my brief notes on DuckLake.

Getting our ducks in a row 🔗

Let’s be clear: Naming things is hard. Even so, the DuckLake name is confusing because it implies a tight-coupling to DuckDB where there is none (other than the ownership of the project).

DuckLake in its most abstract form is a specification for a way to store and catalog data.

An implementation of that specification is available in a DuckDB extension, but in theory any engine could support it.

In this blog post, unless I say otherwise I’m going to be talking about DuckLake the specification.

OK, so what is DuckLake? 🔗

Where does this fit in my data engineering toolbox?

Conceptually, DuckLake is an open table format (OTF) plus a catalog.

So it’s (Iceberg + Polaris), it’s (Delta Lake + Unity), etc.

Physically, DuckLake is data stored as parquet files on object storage, and metadata about those files held in a SQL database. Storing the metadata in a SQL database is a core design decision. It means that you don’t need a catalog (because the metadata store becomes the catalog), as well as resulting in various performance improvements and the removal of metadata file compaction requirements.

👉 The DuckLake manifesto does a good job of outlining the current state of OTFs and challenges, and positioning DuckLake within that.

One bit that caught my eye was the nascent support for inlined data updates, in which the SQL database (currently only DuckDB itself) is also used to hold small bits of data (imagine that! in a database!) instead of directly writing individual changes to a parquet file.

DLF vs OTF—WTF? 🔗

The last few years in data engineering have been marked by numerous explainers on Open Table Formats (OTF), such that we’re fairly comfortable with what they are now.

DuckLake rips this back open, by introducing the "Data Lakehouse Format" (DLF) term.

It makes sense because DuckLake isn’t [just] a open table format, because it bundles the catalog too.

Sounds complicated. Isn’t this just more moving parts? 🔗

Yes, but no.

If you’re using an OTF (Iceberg/Delta Lake/Hudi) for any kind of task beyond a local sandbox and a single user, you’ll need a catalog. DuckLake just wraps these two things together.

Instead of managing object storage + catalog, you manage object storage + SQL database.

Looking at it this way, it’s actually a better option from an operations point of view; catalogs are relatively new technology, whilst DBAs have been feeding and watering SQL databases for decades.

Relationship to Motherduck 🔗

Motherduck wrote a blog post about DuckLake with their own take on the manifesto and positioning of DuckLake. They’re offering to provide the SQL catalog for DuckLake along with the data storage too, optionally. They’ll also do the housekeeping on the data files—remember, even if the metadata files are now in a SQL catalog, there could still be potentially the problem of small data files that need compacting in order for optimal performance.

What about Iceberg? 🔗

DuckDB’s lack of comprehensive support for Iceberg has been notable for a while, and DuckLake doesn’t do anything to fix that unfortunately.

DuckLake and Iceberg are completely unrelated in terms of interaction. If you use Iceberg, you use Iceberg. DuckLake would replace Iceberg (plus its catalog).

In the above blog post, Motherduck position DuckLake as a "hedge" against problems with Iceberg, saying that DuckLake has planned support for import and export to Iceberg. To me this is pretty ironic; why would you adopt a technology that’s entirely unproven and states that it’s not production ready, over one which is being widely adopted and successfully used in scale at production for several years? That’s not to say Iceberg doesn’t have its challenges and maybe one day will be a distant memory as DuckLake takes over the world—but the 'hedge' argument today is somewhat flawed.

Governance 🔗

All the OTFs, and the "DLF" DuckLake are open source licenced. Licensing is just one element of "open" to consider though; the other is how the project is governed. This can impact how easy it is to submit bug fixes, add new features, or even make breaking changes.

Apache Iceberg and Apache Hudi are governed by the Apache Software Foundation. Changes and developments are managed by the PMC, made up of contributors from different companies.

Delta Lake is owned by the Linux Foundation, but in practice is a Databricks project.

DuckLake is owned by the DuckDB Foundation.

Sounds fun, let’s try it! 🔗

Be aware that DuckLake’s not recommended for production use yet.

At the moment the only implementation of DuckLake is in the form of an extension for DuckDB. There are some good examples at the end of the DuckLake announcement blog of its use.

I put together a Docker Compose to run DuckDB (DuckLake engine) and Postgres (metadata catalog) together, using local file system for data.

First off, install the DuckLake and Postgres extensions in DuckDB:

INSTALL ducklake;
INSTALL postgres;

Then create a DuckLake database using Postgres for metadata and local filesystem (/data) for the data files.

ATTACH 'ducklake:postgres:dbname=postgres host=postgres user=postgres password=Welcome123' AS my_ducklake
    (DATA_PATH '/data/');

USE my_ducklake;

Now create a table and add some data:

🟡◗ CREATE TABLE test_data (
      id INTEGER,
      name VARCHAR,
      email VARCHAR,
      age INTEGER,
      registration_date DATE,
      score DOUBLE,
      is_active BOOLEAN
  );

🟡◗ INSERT INTO test_data
  WITH generated_data AS (
      SELECT
          row_number() OVER () AS id,
          'User_' || (row_number() OVER ())::VARCHAR AS name,
          'user' || (row_number() OVER ())::VARCHAR || '@example.com' AS email,
          18 + (random() * 50)::INTEGER AS age,
          DATE '2024-01-01' + (random() * 365)::INTEGER AS registration_date,
          round(random() * 100, 2) AS score,
          random() > 0.3 AS is_active
      FROM range(1000)
  )
  SELECT * FROM generated_data;

Check the data:

🟡◗ SELECT COUNT(*) FROM test_data;
┌──────────────┐
│ count_star() │
│    int64     │
├──────────────┤
│     1000     │
└──────────────┘

🟡◗ SELECT * FROM test_data LIMIT 1;
┌───────┬─────────┬────────────────────┬───────┬───────────────────┬────────┬───────────┐
│  id   │  name   │       email        │  age  │ registration_date │ score  │ is_active │
│ int32 │ varchar │      varchar       │ int32 │       date        │ double │  boolean  │
├───────┼─────────┼────────────────────┼───────┼───────────────────┼────────┼───────────┤
│     1 │ User_1  │ [email protected]  │    64 │ 2024-09-10        │   4.29 │ false     │
├───────┴─────────┴────────────────────┴───────┴───────────────────┴────────┴───────────┤
│ 1 row                                                                       7 columns │
└───────────────────────────────────────────────────────────────────────────────────────┘

Over in Postgres is the metadata:

postgres=# \dt
                         List of relations
 Schema |                 Name                  | Type  |  Owner
--------+---------------------------------------+-------+----------
 public | ducklake_column                       | table | postgres
 public | ducklake_column_tag                   | table | postgres
 public | ducklake_data_file                    | table | postgres
 public | ducklake_delete_file                  | table | postgres
 public | ducklake_file_column_statistics       | table | postgres
 public | ducklake_file_partition_value         | table | postgres
 public | ducklake_files_scheduled_for_deletion | table | postgres
 public | ducklake_inlined_data_tables          | table | postgres
 public | ducklake_metadata                     | table | postgres
 public | ducklake_partition_column             | table | postgres
 public | ducklake_partition_info               | table | postgres
 public | ducklake_schema                       | table | postgres
 public | ducklake_snapshot                     | table | postgres
 public | ducklake_snapshot_changes             | table | postgres
 public | ducklake_table                        | table | postgres
 public | ducklake_table_column_stats           | table | postgres
 public | ducklake_table_stats                  | table | postgres
 public | ducklake_tag                          | table | postgres
 public | ducklake_view                         | table | postgres
(19 rows)

Including the table:

postgres=# select * from ducklake_table;
 table_id |              table_uuid              | begin_snapshot | end_snapshot | schema_id | table_name
----------+--------------------------------------+----------------+--------------+-----------+------------
        1 | 0197314e-9389-7111-a705-3f8341df299c |              1 |              |         0 | test_data
(1 row)

and information about the data file:

postgres=# select * from ducklake_data_file;
 data_file_id | table_id | begin_snapshot | end_snapshot | file_order |                         path                          | path_is_relative | file_format | record_count | file_size_bytes | footer_size | row_id_start | partition_id | encryption_key | partial_file_info
--------------+----------+----------------+--------------+------------+-------------------------------------------------------+------------------+-------------+--------------+-----------------+-------------+--------------+--------------+----------------+-------------------
            0 |        1 |              2 |              |            | ducklake-0197314e-c237-7e2d-9aee-6a954d82401e.parquet | t                | parquet     |         1000 |           36279 |         809 |            0 |              |                |
(1 row)

This corresponds to the data file on disk on the DuckDB container:

docker compose exec -it duckdb ls -l /data
total 36
-rw-r--r-- 1 root root 36279 Jun  2 15:42 ducklake-0197314e-c237-7e2d-9aee-6a954d82401e.parquet

Watch this space 🔗

I can see three posibilities for DuckLake:

  1. It thrives, but only really in the DuckDB world. Having a way to store data with multi-user access is a pretty nice idea, and I can see folk building some good data platforms around DuckDB and DuckLake.

  2. It finds limited adoption, perhaps amongst Motherduck customers who want a fully-hosted service.

  3. It gains broader adoption outside of the DuckDB ecosystem. For this there’d need to be some serious implementations of it in popular engines so that it’s not just the DuckDB fan club who use it. For example, with JDBC support in DuckDB there are some workarounds to access DuckLake from Spark, but it needs to be first-class support in Spark, Trino, etc.
