A few years ago a colleague of mine told me about this thing called Docker, and I must admit I dismissed it as a fad…how wrong was I. Docker, and Docker Compose, are one of my key tools of the trade. With them I can build self-contained environments for tutorials, demos, conference talks etc. Tear it down, run it again, without worrying that somewhere a local config changed and will break things.

So, here’s a collection of tricks I use with Docker and Docker Compose that might be useful, particularly for those working with Apache Kafka and Confluent Platform.

Wait for an HTTP endpoint to be available 🔗

Often a container will be ‘up’ before it’s actually up. So Docker Compose’s depends_on dependencies don’t do everything we need here. For a service that exposes an HTTP endpoint (e.g. Kafka Connect, KSQL Server, etc) you can use this bash snippet to force a script to wait before continuing execution of something that requires the service to actually be ready and available:

Here this is assuming that KSQL Server is running on a host accessible as ksql-server and on port 8088. You can use this trick if, for example, you only want to launch the KSQL CLI once the server is available:

docker-compose exec ksql-cli bash -c 'echo -e "\n\n⏳ Waiting for KSQL to be available before launching CLI\n"; while [ $(curl -s -o /dev/null -w %{http_code} http://ksql-server:8088/) -eq 000 ] ; do echo -e $(date) "KSQL Server HTTP state: " $(curl -s -o /dev/null -w %{http_code} http://ksql-server:8088/) " (waiting for 200)" ; sleep 5 ; done; ksql http://ksql-server:8088'

You can also build it into a Docker Compose file as shown below.

Wait for a particular message in a container’s log 🔗

For the same reason as above—waiting for a service to be ready—you can use this trick built around grep and bash’s process substitution, which will make the script wait until the given phrase is found in the logs from Docker Compose:

export CONNECT_HOST=connect-debezium
echo -e "\n--\n\nWaiting for Kafka Connect to start on $CONNECT_HOST … ⏳"
grep -q "Kafka Connect started" <(docker-compose logs -f $CONNECT_HOST)

Run custom code before launching a container’s program 🔗

Maybe you want to download a dependency, or move some files around, or do something. You could build a new Dockerfile, but often you want to overlay on an existing standard image a slight tweak for a demo. With Docker Compose this is easy enough to do. First you need to figure out what command the container is going to run when it launches, which will either be through Entrypoint or Cmd:

$ docker inspect --format='{{.Config.Entrypoint}}' confluentinc/cp-ksql-server:5.0.1
[]

$ docker inspect --format='{{.Config.Cmd}}' confluentinc/cp-ksql-server:5.0.1
[/etc/confluent/docker/run]

In the above example it’s /etc/confluent/docker/run. So now build this into your Docker Compose:

ksql-server:
  image: confluentinc/cp-ksql-server:5.0.1
  depends_on:
    - kafka
  environment:
    KSQL_BOOTSTRAP_SERVERS: kafka:29092
    KSQL_LISTENERS: http://0.0.0.0:8088
  command:
    - /bin/bash
    - -c
    - |
      mkdir -p /data/maxmind
      cd /data/maxmind
      curl https://geolite.maxmind.com/download/geoip/database/GeoLite2-City.tar.gz | tar xz
      /etc/confluent/docker/run

Now the additional bits will run, and then the container’s intended process will actually run.

The - | is some YAML magic; we’re passing in three arguments to command, and the | tells YAML that the following lines are all part of the same entry. It makes for a much neater and easier to read file than trying to put everything into a single line as is sometimes done with command.

Install a Kafka Connect plugin automatically 🔗

If you want to use a connector plugin that’s not part of the existing docker image, you can install it from Confluent Hub - and script it as follows:

kafka-connect:
  image: confluentinc/cp-kafka-connect:5.1.2
  environment:
    CONNECT_REST_PORT: 8083
    CONNECT_REST_ADVERTISED_HOST_NAME: "kafka-connect"
    CONNECT_PLUGIN_PATH: '/usr/share/java,/usr/share/confluent-hub-components'
    […]
  volumes:
    - $PWD/scripts:/scripts
  command:
    - bash
    - -c
    - |
      confluent-hub install --no-prompt neo4j/kafka-connect-neo4j:1.0.0
      /etc/confluent/docker/run

Note that you must also set CONNECT_PLUGIN_PATH to include the path into which the plugin is being installed, otherwise it won’t be picked up by Kafka Connect.

Build a Kafka Connect image with a custom connector plugin 🔗

Create a Dockerfile:

FROM confluentinc/cp-kafka-connect-base:5.5.0
ENV CONNECT_PLUGIN_PATH="/usr/share/java,/usr/share/confluent-hub-components"
RUN confluent-hub install --no-prompt jcustenborder/kafka-connect-spooldir:2.0.43
  1. This is based on cp-kafka-connect-base
  2. Sets the plugin.path environment variable correctly based on where the confluent-hub client installs the JARs
  3. Use as many confluent-hub install commands as connectors that you want to install (using --no-prompt)

Build the image:

docker build -t my-kafka-connect-image .

Admire your new image

➜ docker images
REPOSITORY               TAG       IMAGE ID            CREATED             SIZE
my-kafka-connect-image   latest    fd44121b673e        17 minutes ago      1.07GB

Deploy a Kafka Connect connector automatically 🔗

In the above example, we run some code before the container’s payload (the KSQL Server) starts because of a dependency on it. In the next example we’ll do it the other way around; launch the service and wait for it to start, and then run some more code. This is the pattern we need for deploying a Kafka Connect connector.

kafka-connect:
  image: confluentinc/cp-kafka-connect:5.1.2
  environment:
    CONNECT_REST_PORT: 18083
    CONNECT_REST_ADVERTISED_HOST_NAME: "kafka-connect"
    […]
  volumes:
    - $PWD/scripts:/scripts
  command:
    - bash
    - -c
    - |
      /etc/confluent/docker/run &
      echo "Waiting for Kafka Connect to start listening on kafka-connect ⏳"
      while [ $$(curl -s -o /dev/null -w %{http_code} http://kafka-connect:8083/connectors) -eq 000 ] ; do
        echo -e $$(date) " Kafka Connect listener HTTP state: " $$(curl -s -o /dev/null -w %{http_code} http://kafka-connect:8083/connectors) " (waiting for 200)"
        sleep 5
      done
      nc -vz kafka-connect 8083
      echo -e "\n--\n+> Creating Kafka Connect Elasticsearch sink"
      /scripts/create-es-sink.sh
      sleep infinity

Notes:

Execute a KSQL script through ksql-cli 🔗

This Docker Compose snippet will run KSQL CLI and pass in a KSQL script for execution to it. The manual EXIT is required because of a NPE bug. The advantage of this method vs running KSQL Server headless with a queries file passed to it is that you can still interact with KSQL this way, but can pre-build the environment to a certain state.

ksql-cli:
  image: confluentinc/cp-ksql-cli:5.0.1
  depends_on:
    - ksql-server
  volumes:
    - $PWD/ksql-scripts/:/data/scripts/
  entrypoint:
    - /bin/bash
    - -c
    - |
      echo -e "\n\n⏳ Waiting for KSQL to be available before launching CLI\n"
      while [ $$(curl -s -o /dev/null -w %{http_code} http://ksql-server:8088/) -eq 000 ]
      do
        echo -e $$(date) "KSQL Server HTTP state: " $$(curl -s -o /dev/null -w %{http_code} http://ksql-server:8088/) " (waiting for 200)"
        sleep 5
      done
      echo -e "\n\n-> Running KSQL commands\n"
      cat /data/scripts/my-ksql-script.sql <(echo 'EXIT')| ksql http://ksql-server:8088
      echo -e "\n\n-> Sleeping…\n"
      sleep infinity

Note that the sleep infinity is required, otherwise the container will exit since all of the defined entrypoint will have executed.

Install a JDBC driver for Kafka Connect 🔗

Two techniques here, depending on whether the JDBC driver is available from a URL as a tar or jar (it needs to be a jar, and the Kafka Connect docker image doesn’t have unzip)

Option 1 : Download the JAR 🔗

  kafka-connect:
    image: confluentinc/cp-kafka-connect:5.1.2
…
    environment:
…
      CONNECT_PLUGIN_PATH: '/usr/share/java'
    command:
      - /bin/bash
      - -c
      - |
        cd /usr/share/java/kafka-connect-jdbc/
        curl https://cdn.mysql.com//Downloads/Connector-J/mysql-connector-java-8.0.13.tar.gz | tar xz
        /etc/confluent/docker/run

The fancy trick here is that curl pulls the tar down and pipes it through tar, directly into the current folder (which is the Kafka Connect JDBC folder). Once it’s done this, it launches the Kafka Connect Docker run script. Note that it doesn’t matter if the JAR is in a sub-folder since Kafka Connect scans recursively for JARs.

Option 2 : JAR is available locally 🔗

Assuming you have the JAR locally, you can just mount it into the Kafka Connect container in the Kafka Connect JDBC folder (or sub-folder).

  kafka-connect:
    image: confluentinc/cp-kafka-connect:5.1.2
…
    volumes:
      - /my/local/folder/with/jdbc-driver/:/usr/share/java/kafka-connect-jdbc/jars/
